Descriere
Managementul energiei |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under power,Under voltage |
| Input current | 15 - 7.5 A |
| Efficiency | 91.5 % |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Total power | 1200 W |
| Max output current (+5V) | 22 A |
| Max output current (+3.3V) | 22 A |
| Max output current (-12V) | 0.3 A |
| Combined power (+3.3V) | 120 W |
| Combined power (+5V) | 120 W |
| Combined power (+12V) | 1200 W |
| Hold time | 19 ms |
| Peak power | 1250 W |
| Power factor | 0.98 |
| Max output current (+12V1) | 55 A |
| Max output current (+12V2) | 50 A |
Conexiune |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (6+2 pin) | 4 |
| CPU power connector (4+4 pin) | Yes |
| Motherboard power cable length | 550 mm |
| PCI Express power cable length | 600 mm |
| Cabling type | Fully-Modular |
| SATA power cable length | 500,650,800,950 mm |
| CPU power cable length | 600 mm |
| EPS power connector (8-pin) | Yes |
| Peripheral (Molex) power cable length | 800,950 mm |
| ATX power connector (20+4 pin) | Yes |
| Number of PATA power connectors | 2 |
| PCI Express connector | Yes |
Performanță |
| Mean time between failures (MTBF) | 100000 h |
| 80 PLUS certification | 80 PLUS Gold |
| Purpose | PC |
| Noise level | 34.3 dB |
| Supported motherboard form factors | ATX |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Bearing technology | Rifle |
| EPS version | 2.92 |
| Silent mode | Yes |
Design |
| Product colour | Black |
| Fan diameter | 120 mm |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| On/off switch | Yes |
| Fan speed | 0 - 2700 RPM |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
Conţinutul de ambalaje |
| Cables included | AC,CPU,PATA,PCIe,SATA |
| Cable tie(s) included | Yes |
Greutate şi dimensiuni |
| Depth | 160 mm |
| Width | 150 mm |
| Height | 86 mm |
| Weight | 1920 g |
Datele de ambalare |
| Package type | Box |
| Package weight | 3190 g |
| Package width | 220 mm |
| Package depth | 284 mm |
| Package height | 100 mm |
Detalii tehnice |
| Sustainability certificates | BSMI,CB,CCC,CE,ENERGY STAR,ErP,Federal Communications Commission (FCC),RoHS,TUV,Triman,UKCA,WEEE,cTUVus |
| Sustainability compliance | Yes |
Date logistice |
| Products per shipping (inner) case | 4 pc(s) |
| Shipping (inner) case length | 298 mm |
| Shipping (inner) case width | 426 mm |
| Shipping (inner) case height | 243 mm |
| Shipping (inner) case net weight | 12700 g |
