Descriere
Managementul energiei |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage |
| Input current | 15/7.5 A |
| Efficiency | 92.4 % |
| AC input frequency | 50/60 Hz |
| AC input voltage | 110 - 240 V |
| Total power | 1200 W |
| Max output current (+5Vsb) | 3 A |
| Max output current (+5V) | 25 A |
| Max output current (+3.3V) | 25 A |
| Max output current (-12V) | 0.5 A |
| Combined power (+3.3V) | 150 W |
| Combined power (+5V) | 150 W |
| Combined power (+12V) | 1200 W |
| Hold time | 23 ms |
| Peak power | 1270 W |
| Power factor | 0.99 |
| Max output current (+12V1) | 100 A |
Conexiune |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 9 |
| PCI Express power connectors (6+2 pin) | 4 |
| Motherboard power cable length | 600 mm |
| PCI Express power cable length | 600 mm |
| Cabling type | Fully-Modular |
| SATA power cable length | 550,700,850,1000 mm |
| CPU power cable length | 700 mm |
| EPS power connector (8-pin) | Yes |
| Peripheral (Molex) power cable length | 1000,850 mm |
| Number of PATA power connectors | 2 |
| EPS power connector (4+4 pin) | Yes |
| PCI Express power connectors (16-pin) | 2 |
Performanță |
| Mean time between failures (MTBF) | 100000 h |
| 80 PLUS certification | 80 PLUS Platinum |
| Purpose | PC |
| Noise level | 32.2 dB |
| Supported motherboard form factors | ATX,Micro ATX,Mini-ATX |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Bearing technology | FDB |
| EPS version | 2.92 |
Design |
| Product colour | Black |
| Fan diameter | 135 mm |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
| On/off switch | Yes |
| Fan speed | 0 - 2600 RPM |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
Conţinutul de ambalaje |
| Cables included | CPU,SATA |
| Cable tie(s) included | Yes |
Greutate şi dimensiuni |
| Depth | 180 mm |
| Width | 150 mm |
| Height | 86 mm |
| Weight | 2040 g |
Datele de ambalare |
| Package type | Box |
| Package weight | 3890 g |
| Package width | 248 mm |
| Package depth | 328 mm |
| Package height | 102 mm |
Detalii tehnice |
| Sustainability certificates | RoHS,Federal Communications Commission (FCC),Triman,UKCA,ENERGY STAR,WEEE,CE,ErP |
| Sustainability compliance | Yes |
| Warranty period | 10 year(s) |
Date logistice |
| Products per shipping (inner) case | 4 pc(s) |
| Shipping (inner) case length | 447 mm |
| Shipping (inner) case width | 282 mm |
| Shipping (inner) case height | 346 mm |
| Shipping (inner) case net weight | 17010 g |
