Technical details |
| |
| |
Processor |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Supported processor sockets | Socket AM5 |
| Compatible processor series | AMD Ryzenâ„¢ 7 |
| Maximum internal memory supported by processor | 256 GB |
Graphics |
| DirectX version | 12.0 |
| On-board graphics card | No |
Features |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | AMD |
| Motherboard chipset | AMD X870 |
| Motherboard form factor | ATX |
| Product colour | White |
| Audio chip | Realtek ALC1220 |
| PC health monitoring | |
| Windows operating systems supported | Windows 11 x64 |
Memory |
| Supported memory module capacities | |
| Supported memory clock speeds | |
| Maximum internal memory | 256 GB |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Number of memory slots | 4 |
| Memory slots type | DIMM |
| Supported memory clock speed (max) | 8000 MHz |
Weight & dimensions |
| Width | 305 mm |
| Height | 35 mm |
| Depth | 244 mm |
Network |
| Ethernet LAN | Yes |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| Wi-Fi | Yes |
| WLAN controller model | MediaTek MT7925 |
Internal I/O |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 4 |
| USB 2.0 connectors | 2 |
| ATX Power connector (24-pin) | Yes |
| USB 3.2 Gen 2x2 connectors | 1 |
| Total number of SATA connectors | 4 |
| EPS power connector (8-pin) | Yes |
| 12V power connector | Yes |
BIOS |
| BIOS type | UEFI AMI |
| Clear CMOS jumper | Yes |
| Clear CMOS button | Yes |
| Desktop Management Interface (DMI) version | 2.7 |
Packaging data |
| Package weight | 2.74 kg |
| Package width | 335 mm |
| Package height | 80 mm |
| Package depth | 270 mm |
Packaging content |
| |
| |
Storage controllers |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, SATA III |
| RAID support | Yes |
| RAID levels | |
| Number of storage drives supported | 4 |
| Number of HDDs supported | 8 |
Rear panel I/O ports |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 2 |
| USB 2.0 ports quantity | 2 |
| S/PDIF out port | Yes |
| Microphone in | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB4 Gen 2x2 ports quantity | 2 |
Expansion slots |
| Number of M.2 (M) slots | 4 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| PCI Express x4 slots | 2 |
Battery |
| Lithium weight per battery | 0.07 g |
| Battery type | CR2032 |
| Battery technology | Lithium-Manganese Dioxide (LiMnO2) |
| Battery weight | 3 g |
| Number of battery cells | 1 |
Logistics data |
| Country of origin | China |
| Products per shipping (inner) case | 1 pc(s) |
