Descriere
Performanță |
| Maximum transfer distance | 550 m |
| Duplex system | Full |
| Fiber optic connector | LC |
| Networking standards | IEEE 802.3z |
| Maximum data transfer rate | 1250 Mbit/s |
| Wavelength | 850 nm |
| Wavelength-division multiplexing (WDM) | No |
| Digital Diagnostics Monitoring (DDM) | Yes |
| Interface type | SFP |
| SFP transceiver type | Fiber optic |
| Multi-mode fiber (MMF) supported | Yes |
| SFP transceiver standard | SX |
Caracteristici
Product colour Silver Certification CE, FCC, UR Housing material Aluminium Hot-Plug support Yes
Managementul energiei
Power consumption (typical) 1 W
Conditii de mediu
Operating temperature (T-T) 0 - 70 °C Operating relative humidity (H-H) 5 - 95 % Storage temperature (T-T) -40 - 85 °C
Greutate şi dimensiuni
Weight 23 g Width 13.9 mm Depth 58.4 mm Height 12.6 mm
Datele de ambalare
Package weight 53 g Package depth 120 mm Package width 90 mm Package height 30 mm Number of products included 1 pc(s)
Detalii tehnice
Sustainability certificates RoHS
Date logistice
Harmonized System (HS) code 85369010 Master (outer) case width 250 mm Master (outer) case length 300 mm Master (outer) case height 200 mm Products per master (outer) case 36 pc(s)
