afișaj
Display diagonal	23.8 "
Display resolution	1920 x 1080 pixels
Display brightness	240 cd/m²
Display number of colours	16.78 million colours
Contrast ratio (typical)	1000:1
Touchscreen	Yes
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Response time	15 ms
Display technology	LCD
Horizontal scan range	30 - 82 kHz
Vertical scan range	50 - 75 Hz
LED backlight	Yes
Touchscreen technology	Projected capacitive system

Conexiune

HDMI ports quantity 1

Audio

Built-in speaker(s) Yes RMS rated power 4 W

Design

Product colour Black VESA mounting Yes Panel mounting interface 100 x 100 mm Screen shape Flat

Performanță

International Protection (IP) code IPX1 On Screen Display (OSD) languages CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN,KOR,RUS

Managementul energiei

Power consumption (typical) 25.5 W AC input voltage 100 - 240 V AC input frequency 50 - 60 Hz Power consumption (off) 0.27 W Power consumption (standby) 0.33 W

Greutate şi dimensiuni

Depth (with stand) 233 mm Width (with stand) 574.6 mm Height (with stand) 432.9 mm Weight (with stand) 8700 g

Datele de ambalare

Package weight 12000 g Package width 680 mm Package height 526 mm Package depth 318 mm

Conţinutul de ambalaje

Cables included AC,Audio (3.5mm),HDMI,USB,VGA

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 20 - 80 % Storage temperature (T-T) -20 - 60 °C Storage relative humidity (H-H) 10 - 95 %

Date logistice

Harmonized System (HS) code 85285210

Alte caracteristici

Aspect ratio 16:9 Display viewable area (HxV) 527.04 x 296.46 mm Built-in camera No Quick start guide Yes Headphone outputs 1 Micro-USB ports quantity 4 Power supply type AC/DC Weight (without stand) 5420 g Dimensions (W x D x H) with stand 574.6 x 233 x 432.9 mm Maximum refresh rate 60 Hz Voltage tolerance 5 %
