Descriere
Conexiune |
| Host interface | PCIe |
| Output interface | Serial |
| Serial ports quantity | 4 |
| Serial interface type | RS-232/422/485 |
Design |
| Internal | Yes |
| Product colour | Black |
| LED indicators | Activity |
Caracteristici |
| Chipset | ASIX - AX99100 |
| Stop bits | 1,1.5,2 |
| FIFO (First In, First Out) | 256 B |
| Baud rate | 921.6 Kbit/s |
| Data bits | 5,6,8,9 |
| Parity bit | Even,Mark,N,Odd,Space |
| Flow control support | Yes |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 70 °C |
| Storage temperature (T-T) | -20 - 80 °C |
| Operating relative humidity (H-H) | 20 - 80 % |
Detalii tehnice |
| Sustainability certificates | RoHS,Trade Agreements Act (TAA) |
| Sustainability compliance | Yes |
Cerinţe de sistem |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 Enterprise,Windows 11 Enterprise x64,Windows 11 Home,Windows 11 Pro,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Server operating systems supported | Windows Server 2016,Windows Server 2019,Windows Server 2022 |
| Linux operating systems supported | Yes |
Greutate şi dimensiuni |
| Width | 109 mm |
| Depth | 121 mm |
| Weight | 60 g |
| Height | 16 mm |
Datele de ambalare |
| Package weight | 273.2 g |
| Package width | 144 mm |
| Package depth | 207 mm |
| Package height | 38 mm |
| Cables included | Ribbon cable |
| Mounting brackets included | Yes |
| User guide | Yes |
Date logistice |
| Master (outer) case width | 685 mm |
| Master (outer) case length | 345 mm |
| Products per master (outer) case | 50 pc(s) |
| Master (outer) case height | 306 mm |
Alte caracteristici |
| Electrostatic Discharge (ESD) protection | 15 kV |
| Cable length | 0.3 m |
