Caracteristicile managementului
Switch type	Unmanaged

Conexiune

Basic switching RJ-45 Ethernet ports quantity 5 Basic switching RJ-45 Ethernet ports type Fast Ethernet (10/100)

Reţea

Auto-negotiation Yes Networking standards IEEE 802.3,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x Auto MDI/MDI-X Yes 10G support No Full duplex Yes

Transmisie de date

MAC address table 2000 entries Jumbo frames support Yes Switching capacity 1 Gbit/s Jumbo frames 2048 Packet buffer memory 0.096 MB Throughput 0.74 Mpps

Design

Product colour Green,Grey Rack mounting No Certification VCCI Class B FCC Class B EN55032 Class A CISPR 32 Class B RCM Class B LED indicators Activity,Link,Power Wall mountable Yes Safety UL60950-1, CSAC22.2 №60950-1, EN60950-1(TUV), CE

Managementul energiei

AC input voltage 100 - 240 V Power consumption (max) 1.7 W AC input frequency 50 - 60 Hz

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -20 - 70 °C Storage relative humidity (H-H) 5 - 95 %

Greutate şi dimensiuni

Width 131 mm Height 30 mm Depth 101 mm Weight 380 g

Date logistice

Harmonized System (HS) code 85176990
