Caracteristici
Surge protection	Yes
Surge energy rating	645 J
UPS topology	Line-Interactive
Noise level	55 dB
Audible alarm(s)	Yes
Output power capacity	3 kVA
Input frequency	50/60 Hz
Output power	2700 W
Output operation voltage (max)	240 V
Output operation voltage (min)	208 V
Efficiency	98.5 %
Waveform	Sine
Emergency Power Off (EPO)	Yes
Crest factor	3:1
Automatic Voltage Regulation (AVR)	Yes
Auto-restart	Yes
Output frequency regulation	50/60 Hz
Hold time (max)	10 ms
Hold time (min)	2 ms

Conexiune

AC outlets quantity 9 AC outlet(s) AC outlet types C13 coupler,C19 coupler Power plug C20 coupler SmartSlot Yes Number of output IEC jumpers 2

Baterie

Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery capacity 738 VAh Battery recharge time 3 h Typical backup time at half load 18 min Battery life (max) 5 year(s) Automatic battery test Yes Typical backup time at full load 6.3 min

Design

Product colour Black Form factor Rackmount/Tower Rack capacity 2U Certification CE, CSA, EAC, EN/IEC 62040-1, EN/IEC 62040-2, IRAM, RCM, UL 1778, VDE, REACH, PEP, EOLI LED indicators Battery replacement Cable length 1.83 m

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m

Detalii tehnice

Sustainability certificates Green Premium,RoHS

Greutate ÅŸi dimensiuni

Weight 37320 g Width 432 mm Depth 667 mm Height 85 mm Package weight 45360 g Package width 596 mm Package depth 869 mm Package height 243 mm

Datele de ambalare

Cables included RS-232,USB cable Manual Yes Rack mount kit Yes Quick installation guide Yes Software CD Yes

Date logistice

Products per pallet 8 pc(s) Harmonized System (HS) code 85078000

Alte caracteristici

Nominal input voltage 230 V Nominal output voltage 230 V
