Caracteristici
Surge protection	Yes
Surge energy rating	645 J
Response time	10 ms
UPS topology	Line-Interactive
Noise level	55 dB
Audible alarm(s)	Yes
Output power capacity	2.2 kVA
Input frequency	50/60 Hz
Output power	1980 W
Input operation voltage (max)	230 V
Input operation voltage (min)	208 V
Output operation voltage (max)	240 V
Output operation voltage (min)	208 V
Waveform	Sine
Output frequency	50/60 Hz
Emergency Power Off (EPO)	Yes
Audible alarm modes	Battery replacement
Auto-restart	Yes
Output voltage regulation	5 %
Output frequency regulation	+/- 3 Hz
Web-based management	Yes

Conexiune

AC outlets quantity 9 AC outlet(s) AC outlet types C13 coupler,C19 coupler,C20 coupler Power plug C20 coupler Ethernet LAN (RJ-45) ports 1 USB 2.0 ports quantity 1

Baterie

Battery technology Sealed Lead Acid (VRLA) Hot-swap battery Yes Battery capacity 702 Ah Battery recharge time 3 h Automatic battery test Yes Cold start Yes

Design

Product colour Black Form factor Rackmount/Tower Rack capacity 2U Certification CE, EAC, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE LED indicators Yes Display type LCD

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -15 - 45 °C Storage relative humidity (H-H) 0 - 95 % Operating altitude 0 - 3000 m Non-operating altitude 0 - 15000 m

Detalii tehnice

Sustainability certificates RoHS

Greutate ÅŸi dimensiuni

Weight 37420 g Width 432 mm Depth 667 mm Height 85 mm Package weight 45260 g Package width 596 mm Package depth 869 mm Package height 243 mm

Datele de ambalare

Cables included Input power cable,USB cable Rack mount kit Yes Quick installation guide Yes Resource CD Yes

Date logistice

Products per pallet 8 pc(s) Harmonized System (HS) code 85078000

Alte caracteristici

Output voltage 230 V
