Processor |
| Compatible processor series | |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Supported processor sockets | Socket AM5 |
Graphics |
| HDCP | Yes |
| Parallel processing technology support | CrossFire |
| Maximum resolution | 3840 x 2160 pixels |
Features |
| Motherboard form factor | micro ATX |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | AMD |
| Windows operating systems supported | |
| Audio chip | Realtek ALC897 |
| Product colour | Black |
| Motherboard chipset | AMD B650 |
Memory |
| Number of memory slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Memory slots type | DIMM |
| Supported memory clock speed (max) | 7200 MHz |
| Supported memory clock speeds | |
| Maximum internal memory | 192 GB |
| Unbuffered memory | Yes |
Weight & dimensions |
| Depth | 244 mm |
| Width | 244 mm |
Network |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| LAN controller | Dragon RTL8125BG |
Internal I/O |
| 12V power connector | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 3 |
| Number of SATA III connectors | 4 |
| ATX Power connector (24-pin) | Yes |
| EPS power connector (8-pin) | Yes |
| Front panel audio connector | Yes |
| TPM connector | Yes |
| Thunderbolt headers | 1 |
| CPU fan connector | Yes |
| USB 2.0 connectors | 2 |
| Chassis intrusion connector | Yes |
| RGB LED pin header | Yes |
| Number of chassis fan connectors | 3 |
BIOS |
| |
| |
Packaging content |
| Screws included | Yes |
| Cables included | SATA |
Storage controllers |
| Supported storage drive interfaces | M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
| RAID levels | |
| RAID support | Yes |
| Number of storage drives supported | 7 |
| Supported storage drive types | HDD & SSD |
Rear panel I/O ports |
| Headphone outputs | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB connector type | |
| DisplayPorts quantity | 1 |
| HDMI version | 2.1 |
| USB 2.0 ports quantity | 4 |
| Microphone in | Yes |
| DisplayPort version | 1.4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
Expansion slots |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 3 |
