Processor |
| Compatible processor series | |
| Processor manufacturer | AMD |
| Processor socket | Socket AM5 |
| Supported processor sockets | Socket AM5 |
Graphics |
| |
| |
Features |
| Windows operating systems supported | |
| Motherboard chipset | AMD A620 |
| Audio output channels | 7.1 channels |
| Motherboard chipset family | AMD |
| Motherboard form factor | micro ATX |
| Cooling type | Passive |
| Power source type | ATX |
Memory |
| Number of memory slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Memory slots type | DIMM |
| Memory channels | Dual-channel |
| Supported memory clock speed (max) | 6400 MHz |
| Supported memory clock speeds | |
| Maximum internal memory | 128 GB |
Weight & dimensions |
| Depth | 244 mm |
| Width | 244 mm |
Network |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | 2.5 Gigabit Ethernet |
Internal I/O |
| Number of COM connectors | 1 |
| 12V power connector | Yes |
| RGB LED pin header | Yes |
| S/PDIF out connector | Yes |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of chassis fan connectors | 2 |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| USB 2.0 connectors | 2 |
BIOS |
| |
| |
Packaging data |
| Package width | 275 mm |
| Package depth | 275 mm |
| Package height | 67.5 mm |
| Package weight | 850 g |
Packaging content |
| User guide | Yes |
| Cables included | SATA |
Storage controllers |
| Number of storage drives supported | 6 |
| Number of HDDs supported | 4 |
| Supported storage drive interfaces | M.2, SATA III |
| RAID levels | |
| Supported storage drive types | HDD & SSD |
| RAID support | Yes |
Rear panel I/O ports |
| Headphone outputs | 1 |
| HDMI version | 2.1 |
| Line-in | Yes |
| PS/2 ports quantity | 1 |
| HDMI ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPort version | 1.4 |
| USB 2.0 ports quantity | 4 |
| DisplayPorts quantity | 2 |
Expansion slots |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| Number of M.2 (M) slots | 2 |
Other features |
| |
| |
