Descriere
Performanță |
| Connectivity technology | Wired |
| Type | IP security camera |
| Certification | EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KCC KN32 Class A, KN35, EN 50121-4, EN 50121-3-2, IEC 62236-4, ECE R10 rev.05 (E approval), EN 50498, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, EN 45545, UN ECE R118, NFPA 130, IEC 62471, IEC/EN 61373 Category 1 Class B, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA 250 Type 4X, IEC/EN 62262 IK10, IEC 60721-3-5 Class 5M3 (vibration and shock), EN 50155 Class OT2/ST2 (2017 Class TX), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-64, IEC 60068-2-78, NIST SP500-267 |
| PTZ control | Yes |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| PTZ modes | Digital PTZ |
| Preset points | Yes |
Design |
| Product colour | Black,White |
| Form factor | Dome |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium |
| IK code | IK10 |
| Fog proof | Yes |
Aparat de fotografiat |
| Minimum illumination | 0.01 lx |
| Tilt angle range | 15 - 90 ° |
| Pan range | -30 - 30 ° |
| Angle of rotation | 350 ° |
| Camera tilt control | Yes |
| Camera pan control | Yes |
| Lens viewing angle, vertical | 62 ° |
| Lens viewing angle, horizontal | 110 ° |
Senzor de imagine |
| Sensor type | CMOS |
| Optical sensor size | 1/2.9 " |
| Progressive scan | Yes |
| Number of sensors | 1 |
Sistem de lentile |
| Fixed focal length | 2.8 mm |
| Number of lenses | 1 |
Video |
| Maximum resolution | 1920 x 1080 pixels |
| Frame rate | 45 fps |
| Video compression formats | AVC,H.264,H.265,HEVC,M-JPEG,MPEG4 |
| Supported graphics resolutions | 160 x 120,160 x 90,1280 x 960,1920 x 1080 (HD 1080) |
| Image quality adjustment | Brightness,Contrast,Sharpness |
| Video streaming | Yes |
| Privacy masking | Yes |
| Total megapixels | 2 MP |
| Text caption overlay | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Image stabilizer | Yes |
Audio |
| Audio formats supported | AAC-LC,G.711,LPCM,PCM |
| Audio system | 1-way |
| Sample rate | 48 kHz |
Reţea |
| Ethernet LAN | Yes |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP, SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT |
| Networking standards | IEEE 802.1x,IEEE 802.3af,IEEE 802.3at |
| Ethernet interface type | Fast Ethernet |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Number of users | 8 user(s) |
Medii de stocare |
| Compatible memory cards | MicroSD (TransFlash),MicroSDHC,MicroSDXC |
| Card reader integrated | Yes |
| Flash memory | 512 MB |
Conexiune |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Yes |
Securitate |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Video motion detection | Yes |
| Password protection | Yes |
| Active tampering alarm | Yes |
Managementul energiei |
| Power source type | PoE |
| Power consumption (typical) | 6.6 W |
| Power consumption (max) | 11.8 W |
Conditii de mediu |
| Operating temperature (T-T) | -40 - 55 °C |
| Operating relative humidity (H-H) | 10 - 95 % |
| Storage temperature (T-T) | -40 - 65 °C |
Greutate ÅŸi dimensiuni |
| Weight | 400 g |
| Height | 49.4 mm |
| Width | 110 mm |
| Depth | 110 mm |
Conţinutul de ambalaje |
| Number of cameras | 1 |
| Manual | Yes |
Date logistice |
| Harmonized System (HS) code | 85258900 |
