Descriere
Managementul energiei |
| Power protection features | Over current,Over power,Over voltage,Overheating,Short circuit,Under voltage |
| Input current | 15 - 9 A |
| Efficiency | 94.5 % |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 115 - 240 V |
| Total power | 1300 W |
| Max output current (+5Vsb) | 3.5 A |
| Max output current (+5V) | 25 A |
| Max output current (+3.3V) | 25 A |
| Max output current (-12V) | 0.5 A |
| Combined power (+3.3V) | 150 W |
| Combined power (+5V) | 150 W |
| Combined power (+12V) | 1300 W |
| Combined power (-12V) | 6 W |
| Combined power (+5Vsb) | 17.5 W |
| Hold time | 18 ms |
| Peak power | 1400 W |
| Power factor | 0.99 |
| Max output current (+12V1) | 35 A |
| Max output current (+12V2) | 35 A |
| Max output current (+12V3) | 40 A |
| Max output current (+12V4) | 40 A |
Conexiune |
| Motherboard power connector | 20+4 pin ATX |
| Number of SATA power connectors | 16 |
| PCI Express power connectors (6+2 pin) | 6 |
| Motherboard power cable length | 600 mm |
| PCI Express power cable length | 600 mm |
| Cabling type | Fully-Modular |
| SATA power cable length | 500,600,750,800,900,950,1050 mm |
| CPU power cable length | 700 mm |
| EPS power connector (8-pin) | Yes |
| Peripheral (Molex) power cable length | 600,750,900,1050 mm |
| ATX power connector (20+4 pin) | Yes |
| Number of PATA power connectors | 5 |
| PCI Express connector | Yes |
| EPS power connector (4+4 pin) | Yes |
Performanță |
| Mean time between failures (MTBF) | 100000 h |
| 80 PLUS certification | 80 PLUS Titanium |
| Purpose | PC |
| Noise level | 23.2 dB |
| Power supply unit (PSU) form factor | ATX |
| ATX version | 3.0 |
| Bearing technology | FDB |
| EPS version | 2.92 |
Design |
| Product colour | Black |
| Fan diameter | 135 mm |
| Number of fans | 1 fan(s) |
| Cooling type | Active |
Conţinutul de ambalaje |
| Cables included | CPU,PCIe,Peripheral (Molex),SATA |
| Cable tie(s) included | Yes |
Greutate şi dimensiuni |
| Depth | 200 mm |
| Width | 150 mm |
| Height | 86 mm |
| Weight | 2410 g |
Datele de ambalare |
| Package weight | 6800 g |
| Package width | 253 mm |
| Package depth | 417 mm |
| Package height | 152 mm |
Detalii tehnice |
| Sustainability certificates | CCC,CE,Federal Communications Commission (FCC),UKCA |
| Sustainability compliance | Yes |
| Warranty period | 10 year(s) |
Date logistice |
| Products per shipping (inner) case | 2 pc(s) |
| Shipping (inner) case length | 440 mm |
| Shipping (inner) case width | 325 mm |
| Shipping (inner) case height | 283 mm |
| Shipping (inner) case net weight | 14400 g |
