Descriere
Conexiune |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| Number of computers controlled | 2 |
| Audio connections | Yes |
| Headphone outputs | 2 |
| Console USB ports quantity | 2 |
| Console ports | 3.5mm headphone,3.5mm mic,DisplayPort,USB A |
| Number of microphone inputs | 2 |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.2 |
| USB version | 2.0 |
| Console DisplayPorts ports quantity | 2 |
Performanță |
| Maximum resolution | 4096 x 2160 pixels |
| Chipset | SN8P2202SG |
| HD type | 4K Ultra HD |
| Video bandwidth | 60 Hz |
| Scan interval | 10,20,30,40,50,60 s |
| Audio channels | 2.0 |
| Data transfer rate (max) | 0.48 Gbit/s |
Design |
| Product colour | Black |
| Rack mounting | No |
| Housing material | Acrylonitrile butadiene styrene (ABS) |
| LED indicators | Yes |
| Cable length | 1.5 m |
| Mean time between failures (MTBF) | 419293 h |
| Push button | Yes |
| Hot keys | Yes |
afișaj |
| Built-in display | No |
Managementul energiei |
| Power source | USB |
Cerinţe de sistem |
| Windows operating systems supported | Windows 10,Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home,Windows 10 Home x64,Windows 10 IOT Core,Windows 10 IoT Enterprise,Windows 10 Pro,Windows 10 Pro x64,Windows 10 x64,Windows 11,Windows 11 Enterprise,Windows 11 Enterprise x64,Windows 11 Home,Windows 11 Pro,Windows 11 x64,Windows 7,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 7 x64,Windows 8,Windows 8 Enterprise,Windows 8 Enterprise x64,Windows 8 Pro,Windows 8 Pro x64,Windows 8 x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Enterprise x64,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Mac operating systems supported | Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 11.0 Big Sur,Mac OS X 12.0 Monterey |
| Other operating systems supported | ChromeOS |
Sustenabilitate |
| Sustainability certificates | RoHS |
| Sustainability compliance | Yes |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90 % |
Greutate şi dimensiuni |
| Weight | 600 g |
| Width | 90 mm |
| Depth | 125 mm |
| Height | 25 mm |
Datele de ambalare |
| Package weight | 700 g |
| Package width | 160 mm |
| Package depth | 100 mm |
| Package height | 210 mm |
Conţinutul de ambalaje |
| Quick installation guide | Yes |
Date logistice |
| Master (outer) case width | 440 mm |
| Products per master (outer) case | 12 pc(s) |
| Master (outer) case height | 345 mm |
| Master (outer) case length | 320 mm |
Alte caracteristici |
| Display resolution at frequency | 4096x2160 @60Hz
3840x2160 @60Hz
5120x1440 @60Hz
3440x1440 @60Hz
2560x1440 @60Hz
2560x1080 @60Hz
1920x1200 @60Hz
1920x1080 @60Hz |
