Descriere
Conexiune |
| DC-in jack | Yes |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| Number of computers controlled | 4 |
| Audio connections | Yes |
| Headphone outputs | 4 |
| Console ports | 3.5mm headphone,DisplayPort,USB A |
| DisplayPorts quantity | 4 |
| DisplayPort version | 1.4 |
| USB 2.0 Type-A hub ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A hub ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 4 |
| Console DisplayPorts ports quantity | 1 |
Performanță
Maximum resolution 7680 x 4320 pixels Chipset GL-3523 HDCP Yes HD type 8K Ultra HD Daisy chain No Scan interval 3,8,15,30 s Data transfer rate (max) 5000 Gbit/s HDCP version 1.4/2.2 High Dynamic Range (HDR) supported Yes
Design
Product colour Black Rack mounting No Housing material Steel LED indicators Yes Mean time between failures (MTBF) 130000 h Push button Yes Hot keys Yes
afișaj
Built-in display No
Managementul energiei
AC input voltage 100 - 240 V Input current 1 A Power source DC Power consumption (typical) 36 W Compatible power plug types EU,JP,UK,US Output current 3 A Output voltage 12 V Power plug type Type M
Sustenabilitate
Sustainability certificates CE,RoHS,Trade Agreements Act (TAA) Sustainability compliance Yes
Conditii de mediu
Operating temperature (T-T) 0 - 40 °C Storage temperature (T-T) -20 - 60 °C Operating relative humidity (H-H) 0 - 85 %
Greutate şi dimensiuni
Weight 1000 g Width 130 mm Depth 220 mm Height 44 mm
Datele de ambalare
Package weight 1600 g Package width 409 mm Package depth 212 mm Package height 87 mm
Conţinutul de ambalaje
Quick installation guide Yes Rubber feet Yes
Date logistice
Master (outer) case width 545 mm Products per master (outer) case 60 pc(s) Master (outer) case height 245 mm Master (outer) case length 427 mm
Alte caracteristici
IP control No
