Design
Type	Single-phase
Product colour	Black
Form factor	Rackmount
Rack capacity	1U
PDU types	Managed
Mounting	Horizontal
Display	LCD
Rack mounting	Yes
Cable colour	Black

Conexiune

Ethernet LAN (RJ-45) ports 1 AC outlets quantity 8 AC outlet(s) AC outlet types C13 coupler Power plug C20 coupler Output connections 8 x C13 Serial ports quantity 1

Caracteristici

Certification CB, CE, EN 60950-\\n1:2006/A11:2009/A1:2010/A12:2011\\nEN 61000-6-2:2005\\nEN 50581 : 2012, REACH, WEEE\\nISO 9001:2008 / ISO 14001:2004 LED indicators Yes Cable length 3 m

Caracteristicile managementului

Supported network protocols HTTP, HTTPS, SSL, FTP, SMTP, DNS, DHCP, LDAP, RADIUS Management protocols SNMP, Telnet Firmware upgradeable Yes Firmware upgradeable via Network,USB

Managementul energiei

Nominal input voltage 230 V AC input frequency 50 Hz Maximum power 3700 W Maximum current 16 A Nominal output voltage 230 V Maximum input current per phase 16 A

Greutate ÅŸi dimensiuni

Weight 3400 g Width 445 mm Height 43 mm Depth 203 mm Dimensions (WxDxH) 445 x 203 x 43 mm

Datele de ambalare

Package width 375 mm Package height 195 mm Package depth 570 mm Package weight 5800 g

Conţinutul de ambalaje

Rack mount kit Yes Cables included LAN (RJ-45)

Conditii de mediu

Operating temperature (T-T) 0 - 60 °C

Detalii tehnice

Sustainability certificates RoHS
