Technical details |
| |
| |
Design |
| |
| |
Power |
| Energy consumption (SDR) per 1000 hours | 14 kWh |
| AC input voltage | 100 - 240 V |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 44 W |
| Power consumption (typical) | 13.5 W |
| AC input frequency | 50 - 60 Hz |
| Energy efficiency scale | A to G |
| Energy efficiency class (SDR) | D |
Operational conditions |
| Operating temperature (T-T) | 5 - 35 °C |
| Operating relative humidity (H-H) | 20 - 80% |
Weight & dimensions |
| Weight (without stand) | 3.7 kg |
| Width (with stand) | 531 mm |
| Depth (without stand) | 45.5 mm |
| Height (without stand) | 341.9 mm |
| Depth (with stand) | 190 mm |
| Height (with stand) | 351.4 mm |
| Weight (with stand) | 5.7 kg |
| Width (without stand) | 531 mm |
Performance |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
Packaging data |
| |
| |
Packaging content |
| Cables included | |
| Quick start guide | Yes |
| Stand included | Yes |
| Manual | Yes |
Thin Client |
| |
| |
Display |
| Panel type | IPS |
| Display brightness (typical) | 350 cd/m² |
| HD type | WUXGA |
| Separate H/V sync | Yes |
| Vertical scan range | 55 - 76 Hz |
| Viewable size, horizontal | 51.8 cm |
| Screen shape | Flat |
| Response time | 5 ms |
| Display diagonal | 61.2 cm (24.1") |
| Viewing angle, horizontal | 178° |
| Pixel pitch | 0.27 x 0.27 mm |
| Display number of colours | 16.78 million colours |
| Display resolution | 1920 x 1200 pixels |
| Display technology | LED |
| Native aspect ratio | 16:10 |
| Viewable size, vertical | 32.4 cm |
| Horizontal scan range | 31 - 81 kHz |
| 3D | No |
| Touchscreen | No |
| Viewing angle, vertical | 178° |
| Supported graphics resolutions | |
| Contrast ratio (typical) | 1000:1 |
Multimedia |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| Built-in camera | No |
| RMS rated power | 2 W |
Ergonomics |
| Tilt adjustment | Yes |
| On Screen Display (OSD) languages | |
| Height adjustment | |
| Pivot | Yes |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Swivelling | Yes |
| Number of OSD languages | 9 |
| Plug and Play | Yes |
| Cable lock slot | No |
| On Screen Display (OSD) | Yes |
Ports & interfaces |
| Headphone outputs | 1 |
| Number of upstream ports | 1 |
| USB upstream port type | USB Type-B |
| DisplayPorts quantity | 1 |
| DVI port | Yes |
| Headphone connectivity | 3.5 mm |
| Headphone out | Yes |
| HDCP | Yes |
| DVI-D ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Built-in USB hub | Yes |
| USB hub version | 3.2 Gen 1 (3.1 Gen 1) |
| USB Type-A downstream ports quantity | 2 |
| HDMI ports quantity | 1 |
Other features |
| Power management | Yes |
| Display | LCD |
| No flickering | Yes |
| On/off switch | Yes |
| TV tuner integrated | No |
Logistics data |
| |
| |
Sustainability |
| European Product Registry for Energy Labelling (EPREL) code | 346702 |
| Sustainability compliance | Yes |
| Sustainability certificates | |
