Reţea
Ethernet LAN data rates	10,100,1000 Mbit/s
Duplex system	Full
Jumbo frames support	Yes
Flow control support	Yes
Networking standards	IEEE 802.1Q,IEEE 802.3,IEEE 802.3ab,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
Maximum data transfer rate	1000 Mbit/s
Ethernet interface type	Fast Ethernet,Gigabit Ethernet
Jumbo frames	9000
Auto MDI/MDI-X	Yes
Converter input interface	100Base-TX,1000Base-T
Converter output interface	1000Base-SX
Store-and-forward	Yes

Conexiune

Connectivity technology Wired Ethernet LAN (RJ-45) ports 1 Fiber optic connector SC Fiber ports quantity 1

Performanță

Maximum transfer distance 550 m Mean time between failures (MTBF) 50000 h Fiber mode structure Multi-mode Wavelength 850 nm Wavelength-division multiplexing (WDM) No

Design

Product colour Black Certification CE, FCC, REACH Internal No LED indicators Activity,Link,Power Housing material Steel

Managementul energiei

Power consumption (typical) 5 W Input current 0.5 A External power adapter Yes Output voltage 5 V Output current 2.6 A Input voltage 100 - 240 V Power plug type Type N

Greutate şi dimensiuni

Weight 200 g Width 97 mm Depth 70 mm Height 26 mm

Conditii de mediu

Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 5 - 90 % Storage temperature (T-T) -10 - 70 °C

Datele de ambalare

Package weight 564 g Package depth 133 mm Package width 280 mm Package height 66 mm

Conţinutul de ambalaje

Quick installation guide Yes AC adapter included Yes

Detalii tehnice

Sustainability certificates RoHS

Date logistice

Harmonized System (HS) code 85176990 Master (outer) case width 595 mm Master (outer) case length 375 mm Master (outer) case height 320 mm Products per master (outer) case 20 pc(s)
