| Processor |
| Processor manufacturer | Intel |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold |
| Processor socket | LGA 1700 |
| Supported processor sockets | LGA 1700 |
| Memory |
| Memory slots type | DIMM |
| Maximum internal memory | 128 GB |
| ECC | Y |
| Number of memory slots | 4 |
| Non-ECC | Y |
| Supported memory clock speed (max) | 8000 MHz |
| Supported memory clock speeds | 8000.7950.7900.7800.4000.4800.5200.5400.5600.5800.6000.6200.6400.6600.6800.7000.7200.7400.7600 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Unbuffered memory | Y |
| Network |
| Ethernet LAN | Y |
| Bluetooth | 5.3 Y |
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| WLAN controller model | Killer Wi-Fi 6E AX1690 |
| LAN controller | Marvell AQtion AQC113C |
| Wi-Fi | Y |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
| Ethernet interface | 10 Gigabit Ethernet |
| Technical details |
| Vendor | Gigabyte |
| Packaging content |
| Cables included | SATA |
| Expansion slots |
| Number of M.2 (M) slots | 5 |
| PCI Express x16 slots | 3 |
| BIOS |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| ACPI version | 5.0 |
| Clear CMOS button | Y |
| Clear CMOS jumper | Y |
| Weight & dimensions |
| Width | 305 mm |
| Depth | 260 mm |
| Graphics |
| Maximum resolution | 4096 x 2304 pixels |
| Parallel processing technology support | Crossfire |
| HDCP | Y |
| Features |
| Motherboard form factor | Extended ATX |
| Audio output channels | 7.1 channels |
| Audio chip | Realtek ALC1220-VB |
| Motherboard chipset | Intel Z790 Express |
| PC health monitoring | Fan, Noise, Temperature, Voltage, Water cooling |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | Intel |
| Component for | PC |
| Internal I/O |
| Thunderbolt headers | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors | 1 |
| Front panel connector | Y |
| 12V power connector | Y |
| USB 2.0 connectors | 2 |
| CPU fan connector | Y |
| ATX Power connector (24-pin) | Y |
| Front panel audio connector | Y |
| TPM connector | Y |
| RGB LED pin header | Y |
| EPS power connector (8-pin) | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Number of SATA III connectors | 4 |
| Rear panel I/O ports |
| DisplayPort version | 1.2 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 7 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 2 |
| Microphone in | Y |
| S (B connector type - B 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity - B 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity - B 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity - PDIF out port - B 3.2 Gen 2x2 Type-C ports quantity) | USB Type-A, USB Type-C - 4 - 1 - 7 - Y - 2 |
| WiFi-AP antenna jack | 2 |
| USB 3.2 Gen 2x2 Type-C ports quantity | 2 |
| DisplayPorts quantity | 1 |
| Storage controllers |
| RAID levels | 0, 1, 5, 10 |
| Supported storage drive types | HDD & SSD |
| Storage interfaces | M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
| RAID support | Y |
| Number of storage drives supported | 9 |
