Design |
| Product colour | White |
| Mounting type | Ceiling/wall |
| Form factor | Bullet |
| International Protection (IP) code | IP67 |
| Housing material | |
Power |
| Power source type | DC, PoE |
| DC output voltage | 12 |
| Power consumption (Power over Ethernet (PoE)) | 9.1 W |
| Power consumption (max) | 7.6 W |
| Power consumption (typical) | 4.5 W |
Security |
| LED indicators | Alarm |
| Mirror | Yes |
| Intelligent Video Surveillance (IVS) system features | |
| Sound effects | Yes |
| Alarm clock | Yes |
| Voice commands | Yes |
| IP address filtering | Yes |
| Video motion detection | Yes |
| Number of Privacy masking areas (panoramic camera) | 8 |
| Light effects | Yes |
Operational conditions |
| Storage temperature (T-T) | -40 - 60 °C |
| Operating temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
Weight & dimensions |
| Weight | 1 kg |
| Package weight | 1.23 kg |
| Width | 94.4 mm |
| Depth | 84.7 mm |
| Length | 288.4 mm |
Network |
| Bluetooth | No |
| Networking standards | |
| Streaming method | Multicast |
| Number of users | 20 user(s) |
| Quality of Service (QoS) support | Yes |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Wi-Fi | No |
Performance |
| Connectivity technology | Wired |
| Placement supported | External / Internal |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Wide Dynamic Range (WDR) | 120 dB |
| Type | IP security camera |
Packaging content |
| |
| |
Audio |
| Built-in microphone | Yes |
| Voice codecs | |
| Speakerphone | Yes |
| Two-way talk | Yes |
| Number of microphones | 2 |
Storage |
| Maximum memory card size | 256 GB |
| Internal memory | 512 MB |
| ROM capacity | 128 MB |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash) |
| Card reader integrated | Yes |
Ports & interfaces |
| Audio RCA outputs | 1 |
| RCA input | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
Camera |
| Tilt angle range | 0 - 90° |
| Maximum frame rate | 30 fps |
| Pan range | 0 - 360° |
| Camera tilt control | Yes |
| Camera shutter speed | 1/3 - 1/100000 s |
| Adjustment shutter speed | Auto/Manual |
| Camera pan control | Yes |
| Lens viewing angle, diagonal | 125° |
| Lens viewing angle, horizontal | 106° |
| Lens viewing angle, vertical | 55° |
| Angle of rotation | 360° |
| Minimum illumination | 0.004 lx |
| White balance | |
Image sensor |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
Video |
| Supported graphics resolutions | |
| Maximum resolution | 3840 x 2160 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Video streaming | Yes |
| Video compression formats | |
| Region of Interest (ROI) encoding | Yes |
| Gain control type | Auto/Manual |
| Frame rate | 30 fps |
| Total megapixels | 8 MP |
| Privacy masking | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | H.264: 32 Kbps–8192 Kbps, H.265: 12 Kbps–8192 Kbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
Night vision |
| Night vision | Yes |
| LED type | IR / White light LED |
| Number of illumination LEDs | 4 |
| Night vision distance | 30 m |
Lens system |
| Number of lenses | 1 |
| Detect distance (wide) | 91 m |
| Observe distance (wide) | 36.4 m |
| Maximum aperture number | 1 |
| Recognize distance (wide) | 18.2 m |
| Fixed focal length | 2.8 mm |
| Identify distance (wide) | 9.1 m |
| Closest focusing distance | 2 m |
