Design |
| International Protection (IP) code | IP66 |
| Form factor | Dome |
| Mounting type | Ceiling/wall |
| IK code | IK10 |
| Product colour | White |
Power |
| Power consumption (max) | 42 W |
| AC input voltage | 24 V |
| Power source type | AC |
Security |
| Video motion detection | Yes |
| IP address filtering | Yes |
| HTTPS encryption | Yes |
| Password protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Face detection |
Operational conditions |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | -30 - 65 °C |
Weight & dimensions |
| Weight | 5 kg |
| Diameter | 22 cm |
Network |
| Number of users | 32 user(s) |
| Networking standards | IEEE 802.1x |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | Yes |
| Quality of Service (QoS) support | Yes |
| Wi-Fi | No |
| Bluetooth | No |
Performance |
| Type | IP security camera |
| Wide Dynamic Range (WDR) | Yes |
| Placement supported | Outdoor |
| Day/night mode | Yes |
| Connectivity technology | Wired |
| Infrared (IR) cut-off filter | Yes |
| Alarm input/output | Yes |
Packaging content |
| |
| |
Audio |
| Built-in speaker(s) | Yes |
| Sample rate | 48 kHz |
| Voice codecs | |
Storage |
| Compatible memory cards | |
| Card reader integrated | Yes |
| Maximum memory card size | 256 GB |
| Built-in HDD | No |
Ports & interfaces |
| |
| |
Camera |
| Camera tilt control | Yes |
| Tilt angle range | -15 - 90° |
| Camera pan control | Yes |
| Pan preset speed | 240 °/sec |
| Tilt speed | 200 °/sec |
| Pan speed | 160 °/sec |
| Camera shutter speed | 1/1 - 1/30000 s |
| Pan range | 0 - 360° |
Image sensor |
| Sensor type | CMOS |
| Number of sensors | 1 |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
Video |
| Supported graphics resolutions | |
| Video compression formats | |
| Gain control type | Auto |
| Video streaming | Yes |
| Image quality adjustment | |
| Maximum resolution | 2560 x 1440 pixels |
| Back Light Compensation (BLC) | Yes |
| Noise reduction | Yes |
| Frame rate | 30 fps |
| Total megapixels | 4 MP |
| Noise reduction technology | 3D noise reduction |
| Region of Interest (ROI) encoding | Yes |
| Highlight Compensation (HLC) | Yes |
Night vision |
| Night vision distance | 200 m |
| Night vision | Yes |
| LED type | IR |
Lens system |
| Number of lenses | 1 |
| Auto focus | Yes |
| Digital zoom | 16x |
| Optical zoom | 32x |
| Maximum aperture number | 1.5 |
| Zoom capability | Yes |
| Focus | Motorized/Manual |
