| Technical details |
| Vendor | Online USV-Systeme AG |
| Output connections | IEC320 C13 |
| Input connections | IEC320 C14 |
| Charging time | 4 h |
| Output frequency | 50/60 Hz |
| Packaging content |
| Cables included | Input power cable, Output power cable, USB cable |
| Bracket | Y |
| Manual | Y |
| Warranty card | Y |
| Quick installation guide | Y |
| Ports & interfaces |
| Serial interface type | RS-232 |
| Serial ports quantity | 1 |
| Serial interface | Y |
| USB 2.0 ports quantity | 1 |
| USB port | Y |
| AC outlets quantity | 4 AC outlet(s) |
| RS-232 ports | 1 |
| Power plug | C14 coupler |
| AC outlet types | C13 coupler |
| Weight & dimensions |
| Height | 88 mm |
| Width | 438 mm |
| Depth | 412 mm |
| Weight | 15500 g |
| Battery |
| Number of batteries supported | 3 |
| Battery recharge time | 8 h |
| Typical backup time at half load | 15 min |
| Typical backup time at full load | 6 min |
| Battery voltage | 12 V |
| Battery capacity | 9 Ah |
| Cold start | Y |
| Design |
| Product colour | Black |
| Rack capacity | 2U |
| Mean time between failures (MTBF) | 50000 h |
| Form factor | Rackmount/Tower |
| International Protection (IP) code | IP20 |
| Display | LCD |
| Performance |
| Waveform | Sine |
| Audible alarm(s) | Y |
| UPS topology | Double-conversion (Online) |
| Noise level | 50 dB |
| Audible alarm modes | Low battery alarm, Overload alarm |
| Cooling type | Active |
| Surge protection features | Fax, Modem, Network |
| Features |
| Package type | Box |
| Power |
| Power supply input frequency | 50/60 Hz |
| Emergency Power Off (EPO) | Y |
| Output power capacity | 1500 VA |
| Maximum current | 11 A |
| Efficiency | 97 % |
| Output power | 1500 W |
| Input operation voltage (max) | 300 V |
| Input operation voltage (min) | 110 V |
| Output operation voltage (min) | 208 V |
| Output operation voltage (max) | 240 V |
| Operational conditions |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 20 - 90 % |
| Certificates |
| Certification | VFI-SS-111 (EN62040-3)\\nEN62040-1\\nEN62040-2\\nCE |
| Management features |
| Management protocols | SNMP |
