| Processor |
| Processor manufacturer | AMD |
| Compatible processor series | AMD Ryzenâ„¢ 5, AMD Ryzen 7 7th Gen, AMD Ryzen 9 7th Gen |
| Processor socket | Socket AM5 |
| Supported processor sockets | Socket AM5 |
| Memory |
| Memory slots type | DIMM |
| Maximum internal memory | 96 GB |
| Number of memory slots | 2 |
| Non-ECC | Y |
| Supported memory clock speed (max) | 6400 MHz |
| Supported memory clock speeds | 4400.4800.5200.5600.6000.6200.6400 MHz |
| Supported memory types | DDR5-SDRAM |
| Memory channels | Dual-channel |
| Unbuffered memory | Y |
| Network |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Ethernet interface | Gigabit Ethernet |
| Technical details |
| Vendor | Gigabyte |
| Packaging content |
| Cables included | SATA |
| Bundled software | Norton Internet Security LAN bandwidth management software |
| Expansion slots |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 slots | 1 |
| PCI Express x1 slots | 1 |
| BIOS |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| ACPI version | 5.0 |
| Clear CMOS jumper | Y |
| Weight & dimensions |
| Width | 230 mm |
| Depth | 225 mm |
| Graphics |
| Maximum resolution | 4096 x 2160 pixels |
| Parallel processing technology support | Not supported |
| HDCP | Y |
| Features |
| Motherboard form factor | micro ATX |
| Audio output channels | 7.1 channels |
| Motherboard chipset | AMD A620 |
| PC health monitoring | Fan, Temperature, Voltage, Water cooling |
| Windows operating systems supported | Windows 10 x64, Windows 11 x64 |
| Motherboard chipset family | AMD |
| Component for | PC |
| Internal I/O |
| Front panel connector | Y |
| 12V power connector | Y |
| USB 2.0 connectors | 2 |
| CPU fan connector | Y |
| ATX Power connector (24-pin) | Y |
| Front panel audio connector | Y |
| TPM connector | Y |
| RGB LED pin header | Y |
| EPS power connector (8-pin) | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Number of SATA III connectors | 4 |
| Rear panel I/O ports |
| DisplayPort version | 1.4 |
| PS (2 ports quantity) | 1 |
| USB connector type | USB Type-A, USB Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 3 |
| Microphone in | Y |
| VGA (D-Sub) ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| DisplayPorts quantity | 1 |
| Storage controllers |
| RAID levels | 0, 1, 10 |
| Supported storage drive types | HDD & SSD |
| Storage interfaces | M.2, SATA III |
| RAID support | Y |
| Number of storage drives supported | 5 |
