| Processor |
| Processor manufacturer | Intel |
| Maximum number of SMP processors | 1 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® |
| Processor socket | LGA 1700 |
| Supported processor sockets | LGA 1700 |
| Memory |
| Memory slots type | DIMM |
| Supported memory module capacities | 8GB, 16GB, 32GB |
| Maximum internal memory | 64 GB |
| ECC | Y |
| Number of memory slots | 2 |
| Non-ECC | Y |
| Supported memory clock speed (max) | 3200 MHz |
| Supported memory clock speeds | 2133.2400.2666.2933.3000.3200 MHz |
| Supported memory types | DDR4-SDRAM |
| Memory channels | Dual-channel |
| Unbuffered memory | Y |
| Network |
| Ethernet LAN | Y |
| Wi-Fi | N |
| Ethernet interface | Gigabit Ethernet |
| Technical details |
| Vendor | Gigabyte |
| Packaging content |
| Cables included | SATA |
| Bundled software | Norton Internet Security (OEM version), LAN bandwidth management software |
| Drivers included | Y |
| Expansion slots |
| Number of M.2 (M) slots | 1 |
| PCI Express x16 slots | 1 |
| PCI Express x1 slots | 1 |
| BIOS |
| BIOS memory size | 256 Mbit |
| BIOS type | UEFI AMI |
| Desktop Management Interface (DMI) version | 2.7 |
| System Management BIOS (SMBIOS) version | 2.7 |
| ACPI version | 5.0 |
| Clear CMOS jumper | Y |
| Weight & dimensions |
| Width | 230 mm |
| Depth | 215 mm |
| Other features |
| Supported DIMM module capacities | 8GB, 16GB |
| Graphics |
| Maximum resolution | 4096 x 2304 pixels |
| Parallel processing technology support | Not supported |
| HDCP | Y |
| Graphics card | HD Graphics |
| Graphics card family | Intel |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card | Y |
| Features |
| Motherboard form factor | micro ATX |
| Audio output channels | 7.1 channels |
| Motherboard chipset | Intel H610 Express |
| Cooling type | Active |
| PC health monitoring | Fan, Temperature, Voltage |
| Windows operating systems supported | Windows 10 x64,Windows 11 x64 |
| Power source type | ATX |
| Motherboard chipset family | Intel |
| Component for | PC |
| Internal I/O |
| Front panel connector | Y |
| 12V power connector | Y |
| USB 2.0 connectors | 2 |
| CPU fan connector | Y |
| Number of COM connectors | 1 |
| ATX Power connector (24-pin) | Y |
| Number of chassis fan connectors | 2 |
| Front panel audio connector | Y |
| TPM connector | Y |
| RGB LED pin header | Y |
| EPS power connector (8-pin) | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 1 |
| Number of SATA III connectors | 4 |
| Serial port headers | 1 |
| Rear panel I/O ports |
| DisplayPort version | 1.2 |
| PS (2 ports quantity) | 2 |
| USB connector type | USB Type-A |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 1 |
| Headphone outputs | 3 |
| Microphone in | Y |
| VGA (D-Sub) ports quantity | 1 |
| DVI-D ports quantity | 1 |
| HDMI ports quantity | 1 |
| HDMI version | 2.0 |
| DisplayPorts quantity | 1 |
| Storage controllers |
| Supported storage drive types | HDD & SSD |
| Storage interfaces | M.2,SATA III |
| Number of HDDs supported | 4 |
| Number of storage drives supported | 5 |
