Features |
| Output power | 480 W |
| Audible alarm modes | Alarm when on battery, Fault, Low battery alarm |
| Output operation voltage (max) | 240 V |
| Power protection features | |
| Input operation voltage (max) | 290 V |
| Surge protection | Yes |
| Output operation voltage (min) | 220 V |
| UPS topology | Line-Interactive |
| Audible alarm(s) | Yes |
| Automatic Voltage Regulation (AVR) | Yes |
| Output power capacity | 0.8 kVA |
| Efficiency | 96.2% |
| Output voltage regulation | 10% |
| Input frequency | 50/60 Hz |
| Output frequency | 50/60 Hz |
| Output frequency regulation | 1 Hz |
| Input operation voltage (min) | 162 V |
| Output power factor | 0.6 |
| Waveform | Pure sine |
Design |
| Product colour | Black |
| Display type | LCD |
| Form factor | Compact |
Operational conditions |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
Weight & dimensions |
| Width | 100 mm |
| Depth | 328 mm |
| Package height | 228 mm |
| Height | 145 mm |
| Weight | 6 kg |
| Package width | 140 mm |
Packaging data |
| Manual | Yes |
| Cables included | Input power cable, USB cable |
Ports & interfaces |
| Ethernet LAN (RJ-45) ports | 2 |
| AC outlets quantity | 2 AC outlet(s) |
| USB 2.0 ports quantity | 1 |
| AC outlet types | Type E |
| USB port | Yes |
Battery |
| Typical backup time at half load | 5 min |
| Battery voltage | 12 V |
| Number of batteries supported | 1 |
| Battery recharge time (90%) | 7 h |
| Battery capacity | 9 Ah |
Logistics data |
| Products per master (outer) case | 4 pc(s) |
| Master (outer) case gross weight | 27.5 kg |
| Master (outer) case height | 250 mm |
| Master (outer) case length | 390 mm |
| Master (outer) case width | 580 mm |
