Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2
MIB support	Yes
System event log	Yes
Configuring Location Settings (CLI)	Yes

Conexiune

SFP module slots quantity 2 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 16

Reţea

Flow control support Yes Networking standards IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3u,IEEE 802.3x,IEEE 802.3at,IEEE 802.3z,IEEE 802.1D,IEEE 802.1w,IEEE 802.1x VLAN support Yes Number of VLANs 256 Link aggregation Yes Auto MDI/MDI-X Yes 10G support No Spanning tree protocol Yes Broadcast storm control Yes Port mirroring Yes Head-of-line (HOL) blocking Yes

Transmisie de date

Jumbo frames support Yes MAC address table 8192 entries Switching capacity 36 Gbit/s Jumbo frames 9216

Securitate

Security algorithms SSL/TLS MAC address filtering Yes Access Control List (ACL) Yes DHCP features DHCP client IGMP snooping Yes SSH/SSL support Yes BPDU filtering/protection Yes Loop protection Yes Access Control List (ACL) rules 512 IGMP entries 256

Specificații (mod transmitere) multicast

Multicast support Yes Number of multicast groups filtered 256

Protocoale

Management protocols SNMP GARP VLAN Registration Protocol (GVRP) Yes

Design

Product colour White Rack mounting Yes LED indicators Yes Reset button Yes

Performanță

Firmware upgradeable Yes

Managementul energiei

AC input frequency 50 - 60 Hz

Conditii de mediu

Heat dissipation 38.9 BTU/h Operating temperature (T-T) 0 - 50 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -20 - 70 °C Storage relative humidity (H-H) 10 - 90 %

Greutate şi dimensiuni

Width 440 mm Depth 203 mm Height 44 mm Weight 2480 g

Date logistice

Harmonized System (HS) code 85176990
