| Software |
| Operating system | N |
| Processor |
| Thermal Design Power (TDP) | 65 W |
| Processor lithography | 14 nm |
| Processor family | Intel |
| Built-in processor | N |
| Network |
| Ethernet LAN | Y |
| LAN controller | Intel® I219-LM |
| Wi-Fi | N |
| Design |
| Chassis type | Low Profile (Slimline) |
| Kensington Lock | Y |
| Product type | PC barebone |
| Cable lock slot type | Kensington |
| LED indicators | HDD, Power |
| VESA mounting | Y |
| Product colour | Black |
| Certification | CE, FCC, RCM, VCCI, RoHS, ErP |
| VESA mounting interface | 75 x 75.100 x 100 mm |
| Safety | CB, ETL, BSMI |
| On (off switch) | Y |
| Cooling type | Active |
| Energy Star certified | Y |
| Storage |
| Supported storage drive types | HDD, SSD |
| NVMe | Y |
| Card reader integrated | N |
| Storage drive interface | M.2, Serial ATA III |
| Number of storage drives supported | 2 |
| Storage drive sizes supported | 2.5 " |
| Technical details |
| Vendor | Shuttle |
| Packaging content |
| AC adapter included | Y |
| Quick start guide | Y |
| Power cord included | Y |
| Drivers included | Y |
| Ports & interfaces |
| DisplayPort version | 1.4 |
| PS (2 ports quantity) | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Headphone outputs | 1 |
| Microphone in | Y |
| DC-in jack | Y |
| VGA (D-Sub) ports quantity | 1 |
| COM ports quantity | 2 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| Expansion slots |
| PCI Express x16 slots | 1 |
| PCI Express slots version | 3.0 |
| Weight & dimensions |
| Height | 72 mm |
| Width | 240 mm |
| Depth | 200 mm |
| Package weight | 3500 g |
| Weight | 2200 g |
| Graphics |
| Graphics card family | Intel |
| On-board graphics card | Y |
| Performance |
| Watch Dog function | Y |
| Trusted Platform Module (TPM) version | 2.0 |
| Compatible processor series | Intel® Celeron®, Intel® Core™ i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel® Pentium® |
| BIOS type | AMI |
| Audio output channels | 7.1 channels |
| Processor socket | LGA 1200 (Socket H5) |
| Harmonized System (HS) code | 84733080 |
| Audio chip | Realtek ALC662 |
| Operating system | N |
| Trusted Platform Module (TPM) | Y |
| Motherboard chipset | Intel H410 |
| Number of processors supported | 1 |
| Windows operating systems supported | Windows 10 Education,Windows 10 Education x64,Windows 10 Enterprise,Windows 10 Enterprise x64,Windows 10 Home x64,Windows 10 Pro,Windows 10 Pro x64,Windows 7 Enterprise,Windows 7 Enterprise x64,Windows 7 Home Basic,Windows 7 Home Basic x64,Windows 7 Home Premium,Windows 7 Home Premium x64,Windows 7 Professional,Windows 7 Professional x64,Windows 7 Starter,Windows 7 Starter x64,Windows 7 Ultimate,Windows 7 Ultimate x64,Windows 8.1,Windows 8.1 Enterprise,Windows 8.1 Pro,Windows 8.1 Pro x64,Windows 8.1 x64 |
| Linux operating systems supported | Y |
| Logistics data |
| Country of origin | China |
| Motherboard |
| Compatible processor series | Celeron,Core i3,Core i5,Core i7,Pentium |
| Processor socket | LGA 1151 (Socket H4) |
| Motherboard chipset | Intel H110 |
| Number of processors supported | 1 |
| Power |
| Power supply | 90 W |
| Power supply type | External AC adapter |
| Number of power supply units | 1 |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19 V |
| AC adapter output current | 4.74 A |
| Operational conditions |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Memory |
| Memory slots type | SO-DIMM |
| Maximum internal memory | 32 GB |
| ECC | N |
| Number of memory slots | 2 |
| Non-ECC | Y |
| Memory voltage | 1.35 V |
| Supported memory clock speeds | 1333.1600 MHz |
| Supported memory types | DDR3L-SDRAM |
| Memory channels | Dual |
| Certificates |
| Certification | FCC, CE, BSMI, C-Tick, RoHS |
| Safety | CB, BSMI, ETL |
| Energy Star certified | Y |
| Audio |
| Audio output channels | 5.1 channels |
| Built-in speaker(s) | N |
| Audio system | HD |
