Technical details |
| Sustainability certificates | |
| Sustainability compliance | Y |
Design |
| Fan diameter | 14 cm |
| Cooling type | Active |
| Product colour | Black |
| Number of fans | 1 fan(s) |
Power |
| Total power | 750 W |
| Efficiency | 90% |
| Combined power (+12V) | 750 W |
| Combined power (+5V) | 150 W |
| AC input frequency | 47 - 63 Hz |
| Input current | 5 - 10 A |
| AC input voltage | 100 - 240 V |
| Power protection features | |
| Combined power (+3.3V) | 150 W |
| Max output current (+5Vsb) | 3 A |
| Max output current (+3.3V) | 20 A |
| Max output current (+5V) | 20 A |
| Combined power (+5Vsb) | 15 W |
| Max output current (+12V) | 62.5 A |
Weight & dimensions |
| Weight | 1.6 kg |
| Depth | 160 mm |
| Height | 86 mm |
| Width | 150 mm |
Performance |
| Purpose | PC/Server |
| EPS version | 2.92 |
| ATX version | 3.0 |
| 80 PLUS certification | 80 PLUS Gold |
| Power supply unit (PSU) form factor | ATX |
Packaging content |
| Cables included | AC, DC |
| Cable tie(s) included | Y |
Ports & interfaces |
| PCI Express power connectors (6+2 pin) | 3 |
| Cabling type | Modular |
| Peripheral (Molex) power connectors (4-pin) | 4 |
| SATA power cable length | |
| Peripheral (Molex) power cable length | |
| EPS power connector (4+4 pin) | Y |
| PCI Express power cable length | 75 cm |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 12 |
| PCI Express power connectors (16-pin) | 1 |
| Motherboard power cable length | 61 cm |
Other features |
| Screws included | Y |
| EPS cable length | 65 cm |
