Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| Switch layer | L2 |
Conexiune |
| Console port | RJ-45 |
| Combo SFP ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Power connector | DC-in jack |
Reţea |
| Flow control support | Yes |
| Networking standards | IEEE 802.1D,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Link aggregation | Yes |
| Copper ethernet cabling technology | 1000BASE-T,100BASE-T,10GBASE-T |
| Auto MDI/MDI-X | Yes |
| Port mirroring | Yes |
Transmisie de date |
| MAC address table | 8000 entries |
| Packet buffer memory | 0.5 MB |
| Throughput | 1488 Mpps |
Design |
| Product colour | White |
| Rack mounting | Yes |
| LED indicators | Yes |
| Certification | UL 1950
FCC/EN55022
VCCI
C-Tick
EN60950 (TUV)
EN55024
CE |
| Form factor | 1U |
| Stackable | No |
Performanță |
| Internal memory | 8 MB |
| Flash memory | 2 MB |
Managementul energiei |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Input current | 0.3 A |
Curent pe cablu net (PoE) |
| Power over Ethernet (PoE) | No |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -25 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95 % |
Greutate ÅŸi dimensiuni |
| Width | 352 mm |
| Depth | 256 mm |
| Height | 43.2 mm |
| Weight | 2380 g |
Date logistice |
| Harmonized System (HS) code | 85176990 |
