Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
| Switch type | Managed |
| Switch layer | L2 |
| MIB support | Yes |
| ARP inspection | Yes |
| Traffic classification | Yes |
| Configuring Location Settings (CLI) | Yes |
Conexiune |
| USB 2.0 ports quantity | 1 |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45/Mini-USB |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
Reţea |
| Ethernet LAN data rates | 100,1000,10000 Mbit/s |
| Networking standards | IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3ah,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u |
| VLAN support | Yes |
| Number of VLANs | 4094 |
| Link aggregation | Yes |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
Transmisie de date |
| Jumbo frames support | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 128 Gbit/s |
| Forwarding rate | 41.67 Mpps |
| Static route | Yes |
| Jumbo frames | 10240 |
| Number of static routes | 16 |
Securitate |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP snooping |
| IGMP snooping | Yes |
| SSH/SSL support | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Web-based authentication |
| Loop protection | Yes |
| Authentication type | RADIUS |
| IGMP entries | 1024 |
Specificații (mod transmitere) multicast |
| Multicast support | Yes |
| IPv4 multicast entries | 1024 |
| IPv6 multicast entries | 1024 |
Design |
| Product colour | Grey |
| LED indicators | Yes |
| Country of origin | China |
| Market segment | Business |
Performanță |
| Mean time between failures (MTBF) | 2026793 h |
| Processor model | ARM7 |
| Internal memory | 512 MB |
| Flash memory | 256 MB |
| Memory type | DRAM |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
Detalii tehnice |
| Products per shipping (inner) case | 1 pc(s) |
Managementul energiei |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 110 - 220 V |
| Power plug type | Type C |
Curent pe cablu net (PoE) |
| Power over Ethernet (PoE) | No |
Conditii de mediu |
| Operating temperature (T-T) | -5 - 50 °C |
| Operating relative humidity (H-H) | 5 - 90 % |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating altitude | 0 - 3000 m |
| Storage relative humidity (H-H) | 5 - 95 % |
| Non-operating altitude | 0 - 4500 m |
Greutate şi dimensiuni |
| Width | 444.5 mm |
| Depth | 240 mm |
| Height | 44 mm |
| Weight | 2780 g |
Datele de ambalare |
| Package weight | 4535.15 g |
| Package width | 336.55 mm |
| Package depth | 549.402 mm |
| Package height | 147.574 mm |
Date logistice |
| Harmonized System (HS) code | 85176990 |
| Quantity per pack | 1 pc(s) |
| Products per master (outer) case | 1 pc(s) |
