Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Unmanaged
Switch layer	L2

Conexiune

Basic switching RJ-45 Ethernet ports quantity 8 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Gigabit Ethernet (copper) ports quantity 8

Reţea

Ethernet LAN data rates 10,100,1000 Mbit/s Cable types supported Cat5e Networking standards IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x Copper ethernet cabling technology 10BASE-T,100BASE-TX,1000BASE-T Auto MDI/MDI-X Yes 10G support No Flow control support Yes Full duplex Yes Head-of-line (HOL) blocking Yes Half duplex Yes

Transmisie de date

MAC address table 8192 entries Jumbo frames support Yes Switching capacity 16 Gbit/s Jumbo frames 9216 Forwarding rate 11.9 Mpps Number of queues 4

Securitate

Queue scheduling algorithms Weighted Round Robin (WRR)

Design

Product colour Grey Rack mounting No Certification UL (UL 60950), CSA (CSA 22.2), CE, FCC 15 (CFR 47) A, FCC B LED indicators Yes

Performanță

Mean time between failures (MTBF) 465437 h Built-in processor Yes Processor frequency 400 MHz

Managementul energiei

Input current 1.25 A Power supply included Yes DC input voltage 48 V

Curent pe cablu net (PoE)

Power over Ethernet (PoE) ports quantity 4 Power over Ethernet (PoE) Yes Total Power over Ethernet (PoE) budget 32 W

Conditii de mediu

Operating temperature (T-T) 0 - 40 °C Operating relative humidity (H-H) 10 - 90 % Storage temperature (T-T) -20 - 70 °C Heat dissipation 130.34 BTU/h Storage relative humidity (H-H) 5 - 90 %

Greutate ÅŸi dimensiuni

Width 160 mm Height 30 mm Depth 129 mm Weight 550 g

Sustenabilitate

Sustainability certificates CE Sustainability compliance Yes

Datele de ambalare

Quick start guide Yes

Date logistice

Harmonized System (HS) code 85176990
