Design |
| Rack mounting | Yes |
| Product colour | Black |
| LED indicators | Yes |
Power |
| Power consumption (max) | 19.5 W |
| AC input voltage | 100 - 240 V |
Security |
| DHCP features | DHCP client |
| IGMP snooping | Yes |
| Security algorithms | |
| Queue scheduling algorithms | |
Operational conditions |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 2000 m |
| Operating relative humidity (H-H) | 0 - 95% |
| Heat dissipation | 107.5 BTU/h |
Management features |
| Web-based management | Yes |
| Switch type | Managed |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2 |
| System event log | Yes |
Weight & dimensions |
| Width | 280 mm |
| Depth | 230 mm |
| Weight | 2.2 kg |
| Height | 44 mm |
Network |
| Networking standards | |
| VLAN support | Yes |
| Port mirroring | Yes |
| Copper ethernet cabling technology | |
| Number of VLANs | 128 |
| Full duplex | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Virtual LAN features | |
| Flow control support | Yes |
| Auto-negotiation | Yes |
| Rate limiting | Yes |
| Link aggregation | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| Head-of-line (HOL) blocking | Yes |
Performance |
| Processor frequency | 125 MHz |
| Mean time between failures (MTBF) | 255003 h |
| Built-in processor | Yes |
| Flash memory | 16 MB |
| Memory type | DRAM |
| Fanless | Yes |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Logistics data |
| |
| |
Data transmission |
| Switching capacity | 48 Gbit/s |
| Packet buffer memory | 4.1 MB |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Forwarding rate | 35.71 Mpps |
| Number of queues | 4 |
| Store-and-forward | Yes |
| Jumbo frames | 9216 |
Power over Ethernet (PoE) |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) power per port | 30 W |
| Total Power over Ethernet (PoE) budget | 100 W |
| Power over Ethernet plus (PoE+) ports quantity | 12 |
Multicast features |
| |
| |
