| Network |
| Networking standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x |
| Full duplex | Y |
| Auto MDI (MDI-X) | Y |
| 10G support | Y |
| Technical details |
| Vendor | D-Link |
| Pallet gross width | 1200 mm |
| Pallet gross length | 1100 mm |
| Shipping (inner) case width | 296 mm |
| Shipping (inner) case length | 529 mm |
| Shipping (inner) case height | 383 mm |
| Shipping (inner) case gross weight | 11322 g |
| Products per shipping (inner) case | 3 pc(s) |
| Shipping (inner) case net weight | 7491 g |
| Pallet gross weight (air) | 471380 g |
| Master (outer) cases per pallet (air) | 40 pc(s) |
| Products per pallet (air) | 120 pc(s) |
| Pallet height (air) | 2050 mm |
| Pallet gross weight (sea) | 471380 g |
| Master (outer) cases per pallet (sea) | 40 pc(s) |
| Products per pallet (sea) | 120 pc(s) |
| Pallet height (sea) | 2050 mm |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| Power connector | DC-in jack |
| Weight & dimensions |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 210 mm |
| Weight | 2000 g |
| Design |
| LED indicators | Y |
| Product colour | Black |
| Certification | CE, FCC, C-Tick, VCCI, BSMI, CCC |
| Stackable | Y |
| Rack mounting | Y |
| Safety | cUL, CB |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) | N |
| Performance |
| Noise level | 47.5 dB |
| Logistics data |
| Harmonized System (HS) code | 85176990 |
| Power |
| Power consumption (typical) | 24 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
| Operational conditions |
| Operating temperature (T-T) | -5 - 50 °C |
| Storage relative humidity (H-H) | 0 - 95 % |
| Heat dissipation | 72.292 BTU/h |
| Operating relative humidity (H-H) | 0 - 95 % |
| Storage temperature (T-T) | -20 - 70 °C |
| Data transmission |
| Packet buffer memory | 1.5 MB |
| Throughput | 68.45 Mpps |
| Number of static routes | 512 |
| Switching capacity | 92 Gbit/s |
| Jumbo frames support | Y |
| Store-and-forward | Y |
| MAC address table | 16000 entries |
| Packaging data |
| Package depth | 511 mm |
| Package height | 91 mm |
| Package width | 348 mm |
| Package weight | 3474 g |
| Security |
| MAC address filtering | Y |
| Static port security | Y |
| Access Control List (ACL) | Y |
| SSH (SSL support) | Y |
| Management features |
| Switch layer | L3 |
| Quality of Service (QoS) support | Y |
| Switch type | Managed |
