Caracteristicile managementului
Quality of Service (QoS) support	Yes
Web-based management	Yes
Switch type	Managed
Switch layer	L2/L3

Conexiune

Console port RJ-45 Basic switching RJ-45 Ethernet ports type 10G Ethernet (100/1000/10000) Basic switching RJ-45 Ethernet ports quantity 24 SFP28 ports quantity 4 10G Ethernet (copper) ports quantity 24

Reţea

Flow control support Yes Networking standards IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3an,IEEE 802.3az,IEEE 802.3u,IEEE 802.3z VLAN support Yes Number of VLANs 4094 Link aggregation Yes Auto MDI/MDI-X Yes Spanning tree protocol Yes Port mirroring Yes Cable types supported Cat6,Cat6a,Cat7

Transmisie de date

Jumbo frames support Yes MAC address table 32000 entries Switching capacity 680 Gbit/s Forwarding rate 505.92 Mpps Jumbo frames 9000 Store-and-forward Yes

Securitate

Access Control List (ACL) Yes IGMP snooping Yes Access Control List (ACL) rules 256

Protocoale

Management protocols SNMP v1/v2c/v3 GARP VLAN Registration Protocol (GVRP) Yes

Design

Product colour Black Rack mounting Yes LED indicators Activity,Link,Speed Number of fans 2 fan(s) Certification CE Class A FCC Class A VCCI Class A IC BSMI Form factor 1U

Performanță

Noise level 51.9 dB

Managementul energiei

AC input voltage 100 - 240 V Power consumption (max) 87.3 W

Curent pe cablu net (PoE)

Power over Ethernet (PoE) No

Conditii de mediu

Operating temperature (T-T) -5 - 50 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -20 - 70 °C Storage relative humidity (H-H) 0 - 95 %

Greutate ÅŸi dimensiuni

Width 441 mm Depth 209.5 mm Height 44 mm Weight 3070 g

Date logistice

Harmonized System (HS) code 85176990
