Caracteristicile managementului
Quality of Service (QoS) support	Yes
Switch type	Managed
Switch layer	L2
MIB support	SMIv1/SMIv2, IP, TCP, UDP
ARP inspection	Yes

Conexiune

USB 2.0 ports quantity 1 SFP module slots quantity 2 Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000) Basic switching RJ-45 Ethernet ports quantity 10 Power connector AC-in jack

Reţea

Flow control support Yes Auto-negotiation Yes Networking standards IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.1x,IEEE 802.2,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ac,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3ap,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z VLAN support Yes Link aggregation Yes Full duplex Yes 10G support No Broadcast storm control Yes Port mirroring Yes

Transmisie de date

MAC address table 16000 entries Switching capacity 176 Gbit/s Forwarding rate 164 Mpps Store-and-forward Yes

Securitate

Security algorithms 802.1x RADIUS,SSH,SSL/TLS IGMP snooping Yes Authentication type RADIUS

Specificații (mod transmitere) multicast

Multicast support Yes

Design

Product colour Black Rack mounting Yes LED indicators Yes Form factor 1U Stackable Yes

Performanță

Operating system installed OS6

Managementul energiei

AC input frequency 50 - 60 Hz AC input voltage 100 - 240 V Power consumption (max) 137 W Number of power supply units 1 Power source AC Power supply included Yes

Curent pe cablu net (PoE)

Power over Ethernet plus (PoE+) ports quantity 8 Power over Ethernet (PoE) Yes

Conditii de mediu

Operating temperature (T-T) 0 - 45 °C Operating relative humidity (H-H) 0 - 95 % Storage temperature (T-T) -40 - 65 °C Storage relative humidity (H-H) 0 - 85 %

Greutate ÅŸi dimensiuni

Width 215.9 mm Depth 254 mm Height 44.45 mm Weight 1810 g

Date logistice

Harmonized System (HS) code 85176990

Alte caracteristici

Cable length 2 m
