| Network |
| Auto-negotiation | Y |
| Networking standards | IEEE 802.1p,IEEE 802.3at |
| Full duplex | Y |
| Auto MDI (MDI-X) | Y |
| 10G support | N |
| Technical details |
| Vendor | Netgear |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Weight & dimensions |
| Height | 43 mm |
| Width | 330 mm |
| Depth | 206 mm |
| Weight | 2440 g |
| Design |
| LED indicators | Activity,Link,PoE,Power,Speed |
| Product colour | Black |
| Certification | CB, CE LVD, UL |
| Number of fans | 1 fan(s) |
| Rack mounting | Y |
| Housing material | Metal |
| Electromagnetic compatibility | CE, FCC 15 A, IC A, RCM, VCCI, KC |
| Form factor | 1U |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) ports quantity | 16 |
| Total Power over Ethernet (PoE) budget | 190 W |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) | Y |
| Performance |
| Mean time between failures (MTBF) | 1193574 h |
| Power |
| Input current | 3 A |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 210 W |
| Operational conditions |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage relative humidity (H-H) | 10 - 95 % |
| Heat dissipation | 718.2 BTU/h |
| Operating altitude | 0 - 3000 m |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -20 - 70 °C |
| Data transmission |
| Packet buffer memory | 0.192 MB |
| Latency (1 Gbps) | 4 µs |
| Switching capacity | 48 Gbit/s |
| Packet forwarding rate (1 Gbps) | 1448000 pps |
| Jumbo frames | 10000 |
| Jumbo frames support | Y |
| MAC address table | 8000 entries |
| Security |
| Queue scheduling algorithms | Weighted Round Robin (WRR) |
| Management features |
| Quality of Service (QoS) support | Y |
| Switch type | Unmanaged |
