Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Switch layer | L3 |
Conexiune |
| USB 2.0 ports quantity | 1 |
| Console port | RJ-45/Mini-USB |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
Reţea |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1s,IEEE 802.1v,IEEE 802.1w,IEEE 802.3,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3bz,IEEE 802.3u |
| VLAN support | Yes |
| Number of VLANs | 4093 |
| Link aggregation | Yes |
| Virtual LAN features | Private VLAN,Tagged VLAN,Voice VLAN |
| 10G support | Yes |
| IP routing | Yes |
| Port mirroring | Yes |
| Auto-sensing | Yes |
Transmisie de date |
| Jumbo frames support | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 320 Gbit/s |
| Jumbo frames | 9000 |
| Throughput | 238 Mpps |
| Number of queues | 8 |
| Number of static routes | 64 |
| Store-and-forward | Yes |
Securitate |
| Access Control List (ACL) | Yes |
| DHCP features | DHCP client,DHCP snooping,DHCPv6 client,DHCPv6 relay,DHCPv6 server,DHCPv6 snooping |
| IGMP snooping | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN,MAC-based authentication |
Specificații (mod transmitere) multicast |
| Multicast support | Yes |
| Number of multicast groups filtered | 4000 |
Protocoale |
| Routing protocols | OSPF,OSPFv3,RIP,RIP-1,RIP-2 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
Design |
| Product colour | Black |
| Rack mounting | Yes |
| Form factor | 1U |
| Stackable | Yes |
| Airflow direction | Front-to-back airflow |
Performanță |
| Mean time between failures (MTBF) | 690301 h |
| Noise level | 36 dB |
| Internal memory | 1024 MB |
| Built-in processor | Yes |
| Processor frequency | 800 MHz |
| Physical stacking (units) | 8 |
Managementul energiei |
| Power consumption (max) | 49 W |
| Number of power supply units | 1 |
| Power supply included | Yes |
Curent pe cablu net (PoE) |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 199 W |
| Power over Ethernet (PoE) power per port | 30 W |
Conditii de mediu |
| Heat dissipation | 186 BTU/h |
Greutate ÅŸi dimensiuni |
| Width | 212 mm |
| Depth | 345 mm |
| Height | 44 mm |
| Weight | 3220 g |
Datele de ambalare |
| Rack mount kit | Yes |
Date logistice |
| Harmonized System (HS) code | 85176990 |
