Network |
| Auto-sensing |
Y |
| Auto-negotiation |
Y |
| Networking standards |
IEEE 802.3ad,IEEE 802.3az |
| Flow control support |
Y |
| Port mirroring |
Y |
| Link aggregation |
Y |
| Rate limiting |
Y |
| IP routing |
Y |
| Virtual LAN features |
Private VLAN |
| Number of VLANs |
4000 |
| VLAN support |
Y |
| 10G support |
Y |
| Cable types supported |
Cat5,Cat5e,Cat6,Cat7 |
| |
Technical details |
| Vendor |
Netgear |
| |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type |
10G Ethernet (100/1000/10000) |
| Basic switching RJ-45 Ethernet ports quantity |
24 |
| USB 2.0 ports quantity |
1 |
| SFP+ module slots quantity |
24 |
| Console port |
RJ-45/Mini-USB |
| Fiber optic connector |
SFP+ |
| |
Optical fiber |
| Fiber ethernet cabling technology |
10GBASE-LR,10GBASE-LRM,10GBASE-SR |
| |
Weight & dimensions |
| Height |
44 mm |
| Width |
440 mm |
| Depth |
345 mm |
| Weight |
6120 g |
| |
Design |
| LED indicators |
Activity,Power,Speed |
| Product colour |
Black |
| Stackable |
Y |
| Rack mounting |
Y |
| Safety |
CSA 22.2 #950, UL 1950)/cUL IEC 950/EN 60950 |
| Electromagnetic compatibility |
CE, FCC 15 A, VCCI A, A EN 55022, (CISPR 22) A, EN 50082-1, EN 55024 |
| Form factor |
1U |
| |
Power over Ethernet (PoE) |
| Power over Ethernet (PoE) |
N |
| |
Performance |
| Noise level |
35.8 dB |
| Processor frequency |
800 MHz |
| Mean time between failures (MTBF) |
133176 h |
| Flash memory |
256 MB |
| Internal memory |
1024 MB |
| Built-in processor |
Y |
| |
Multicast features |
| Number of multicast groups filtered |
4000 |
| Multicast support |
Y |
| |
Power |
| Power consumption (max) |
161 W |
| Power supply included |
Y |
| |
Operational conditions |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage relative humidity (H-H) |
0 - 95 % |
| Non-operating altitude |
0 - 3000 m |
| Heat dissipation |
133176 BTU/h |
| Operating altitude |
0 - 3000 m |
| Operating relative humidity (H-H) |
0 - 90 % |
| Storage temperature (T-T) |
-20 - 70 °C |
| |
Data transmission |
| Packet buffer memory |
56 MB |
| Latency (10 Gbps) |
2.39 µs |
| Number of static routes |
64 |
| Switching capacity |
960 Gbit/s |
| Jumbo frames |
12000 |
| Jumbo frames support |
Y |
| Store-and-forward |
Y |
| MAC address table |
128000 entries |
| Forwarding rate |
714 Mpps |
| |
Packaging data |
| Rack mount kit |
Y |
| Cables included |
AC,LAN (RJ-45),Mini-USB |
| Resource CD |
Y |
| Rubber feet |
Y |
| |
Security |
| BPDU filtering (protection) |
Y |
| Access Control List (ACL) |
Y |
| DHCP features |
DHCP server,DHCP client |
| Security algorithms |
HTTPS,SNMP,SSH |
| SSH (SSL support) |
Y |
| |
Management features |
| ARP inspection |
Y |
| Switch layer |
L2/L3/L4 |
| Quality of Service (QoS) support |
Y |
| Web-based management |
Y |
| Switch type |
Managed |
