Design |
| Stackable | No |
| Form factor | 1U |
| Number of fans | 2 fan(s) |
| Rack mounting | Yes |
| LED indicators | |
| Product colour | Black |
Power |
| Power supply included | Yes |
| Power source | AC |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 217.22 W |
| AC input frequency | 50 - 60 Hz |
Operational conditions |
| Heat dissipation | 741.15 BTU/h |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Management features |
| |
| |
Weight & dimensions |
| Width | 440 mm |
| Depth | 180 mm |
| Height | 44 mm |
Network |
| Copper ethernet cabling technology | |
| MAC address auto-aging supported | Yes |
| MAC address auto-learning supported | Yes |
| Auto-negotiation | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Networking standards | |
Packaging data |
| Package depth | 528 mm |
| Package height | 80 mm |
| Manual | Yes |
| Cables included | LAN (RJ-45) |
| Package type | Box |
| Package width | 250 mm |
| Package weight | 2.96 kg |
Ports & interfaces |
| Combo SFP ports quantity | 2 |
| Fast Ethernet (copper) ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports quantity | 20 |
| Gigabit Ethernet (copper) ports quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Logistics data |
| |
| |
Data transmission |
| Packet buffer memory | 4.1 MB |
| MAC address table | 8000 entries |
| Switching capacity | 7.2 Gbit/s |
| Forwarding rate | 5.36 Mpps |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Jumbo frames | 10000 |
Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget | 192 W |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet (PoE) | Yes |
