Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Switch type | Managed |
| Switch layer | L2 |
| Web-based management | Yes |
| System event log | Yes |
| Configuring Location Settings (CLI) | Yes |
| ARP inspection | Yes |
Conexiune |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Gigabit Ethernet (copper) ports quantity | 4 |
| Combo SFP ports quantity | 2 |
| Fast Ethernet (copper) ports quantity | 24 |
Reţea |
| Cable types supported | Cat5,Cat5e |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Flow control support | Yes |
| VLAN support | Yes |
| Port mirroring | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Rate limiting | Yes |
| Number of VLANs | 512 |
Transmisie de date |
| MAC address table | 8000 entries |
| Jumbo frames support | Yes |
| Switching capacity | 12.8 Gbit/s |
| Jumbo frames | 9000 |
| Packet buffer memory | 4.1 MB |
| Number of queues | 4 |
| Throughput | 9.5 Mpps |
Securitate |
| Security algorithms | SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| SSH/SSL support | Yes |
Specificații (mod transmitere) multicast |
| Multicast support | Yes |
Protocoale |
| Management protocols | SNMP v1/v2c/v3, RMON, SNTP, TFTP |
Design |
| Product colour | Black |
| Rack mounting | Yes |
| Certification | CE, FCC, RoHS |
| Form factor | 1U |
| Number of fans | 2 fan(s) |
Performanță |
| Firmware upgradeable | Yes |
| Compatible operating systems | Microsoft Windows XP, Vista, Windows 7, Windows 8, MAC OS, NetWare, UNIX, Linux |
Managementul energiei |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 291.6 W |
| AC input frequency | 50/60 Hz |
| Power source | AC |
Curent pe cablu net (PoE) |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 250 W |
| Power over Ethernet plus (PoE+) ports quantity | 24 |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Heat dissipation | 995.09 BTU/h |
| Storage relative humidity (H-H) | 5 - 90 % |
Greutate ÅŸi dimensiuni |
| Width | 440 mm |
| Height | 44 mm |
| Depth | 180 mm |
Datele de ambalare |
| Quick start guide | Yes |
| Cables included | AC |
| Rack mount kit | Yes |
