Descriere
Caracteristicile managementului |
| Quality of Service (QoS) support | Yes |
| Switch type | Unmanaged |
Conexiune |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
Reţea |
| Auto-negotiation | Yes |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e,Cat6 |
| Networking standards | IEEE 802.1p,IEEE 802.3ab,IEEE 802.3af,IEEE 802.3at,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T,100BASE-TX,1000BASE-T |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Flow control support | Yes |
| MAC address auto-learning supported | Yes |
| MAC address auto-aging supported | Yes |
Transmisie de date |
| MAC address table | 2000 entries |
| Jumbo frames support | Yes |
| Switching capacity | 10 Gbit/s |
| Jumbo frames | 16000 |
| Forwarding rate | 7.44 Mpps |
| Store-and-forward | Yes |
Securitate |
| IGMP snooping | Yes |
Design |
| Product colour | Black |
| Rack mounting | No |
| Certification | FCC, CE, RoHS |
| LED indicators | Yes |
| Wall mountable | Yes |
Performanță |
| Fanless | Yes |
Managementul energiei |
| AC input voltage | 100 - 240 V |
| Power consumption (max) | 47.5 W |
| AC input frequency | 50/60 Hz |
| Power supply included | Yes |
Curent pe cablu net (PoE) |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 40 W |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
Conditii de mediu |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Heat dissipation | 161.98 BTU/h |
| Storage relative humidity (H-H) | 5 - 90 % |
Greutate ÅŸi dimensiuni |
| Width | 99.8 mm |
| Height | 25 mm |
| Depth | 98 mm |
Datele de ambalare |
| Package weight | 730 g |
| Package width | 131 mm |
| Package depth | 196 mm |
| Package height | 121 mm |
| User guide | Yes |
Date logistice |
| Harmonized System (HS) code | 85176990 |
