| Network |
| Auto-negotiation | Y |
| Networking standards | IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3i,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
| Flow control support | Y |
| Port mirroring | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Virtual LAN features | MAC address-based VLAN,Protocol-based VLAN,Voice VLAN |
| Auto MDI (MDI-X) | Y |
| Number of VLANs | 4000 |
| Spanning tree protocol | Y |
| VLAN support | Y |
| 10G support | N |
| Copper ethernet cabling technology | 10BASE-T,10BASE-TX |
| Cable types supported | Cat3,Cat4,Cat5,Cat5e |
| Technical details |
| Vendor | TP-LINK |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Fiber ports quantity | 4 |
| Fiber optic connector | SFP |
| Optical fiber |
| Fiber ethernet cabling technology | 1000BASE-X |
| Weight & dimensions |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 220 mm |
| Design |
| Product colour | Black |
| Certification | CE, FCC, RoHS |
| Number of fans | 2 fan(s) |
| Rack mounting | Y |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) ports quantity | 24 |
| Power over Ethernet (PoE) | Y |
| Performance |
| Firmware upgradeable | Y |
| Multicast features |
| Multicast support | Y |
| Power |
| Power consumption (max) | 308.6 W |
| Operational conditions |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 1052.94 BTU/h |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Data transmission |
| Switching capacity | 56 Gbit/s |
| Jumbo frames | 9000 |
| Jumbo frames support | Y |
| Number of queues | 8 |
| MAC address table | 8000 entries |
| Forwarding rate | 41.7 Mpps |
| Packaging data |
| Rack mount kit | Y |
| Cables included | AC |
| User guide | Y |
| Security |
| Authentication type | RADIUS |
| Loop protection | Y |
| BPDU filtering (protection) | Y |
| IP-MAC-Port binding | Y |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| Access Control List (ACL) | Y |
| DHCP features | DHCP relay,DHCP server,DHCP snooping,DHCPv6 client |
| Security algorithms | HTTPS,SNMP,SNMPv2,SNMPv3,SSH,SSH-2,SSL/TLS |
| IGMP snooping | Y |
| Management features |
| ARP inspection | Y |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| System event log | Y |
