| Network |
| Networking standards | IEEE 802.11d,IEEE 802.1s,IEEE 802.1w |
| Active link detection | Y |
| Flow control support | Y |
| Port mirroring | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Policy-based routing | Y |
| Rate limiting | Y |
| Ethernet LAN data rates | 10.100.1000 Mbit/s |
| Spanning tree protocol | Y |
| Head-of-line (HOL) blocking | Y |
| VLAN support | Y |
| 10G support | N |
| Technical details |
| Vendor | TP-LINK |
| Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP+ module slots quantity | 4 |
| Console port | RJ-45/micro-USB |
| Weight & dimensions |
| Height | 44 mm |
| Width | 440 mm |
| Depth | 180 mm |
| Design |
| LED indicators | Y |
| Product colour | Black |
| Rack mounting | Y |
| Power over Ethernet (PoE) |
| Power over Ethernet (PoE) | N |
| Multicast features |
| Multicast support | Y |
| Power |
| Power consumption (typical) | 23.6 W |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply included | Y |
| Operational conditions |
| Operating temperature (T-T) | 0 - 45 °C |
| Storage relative humidity (H-H) | 5 - 90 % |
| Heat dissipation | 80.353 BTU/h |
| Operating relative humidity (H-H) | 10 - 90 % |
| Storage temperature (T-T) | -40 - 70 °C |
| Data transmission |
| Number of static routes | 48 |
| Switching capacity | 128 Gbit/s |
| Jumbo frames support | Y |
| MAC address table | 16000 entries |
| Forwarding rate | 95.23 Mpps |
| Packaging data |
| Cables included | LAN (RJ-45) |
| Quick start guide | Y |
| Security |
| Loop protection | Y |
| IGMP proxy | Y |
| DHCP features | DHCP snooping |
| IGMP snooping | Y |
| Management features |
| ARP inspection | Y |
| MIB support | Yes |
| Switch layer | L2+ |
| Quality of Service (QoS) support | Y |
| Configuring Location Settings (CLI) | Y |
| Web-based management | Y |
| System event log | Y |
| Switch type | Managed |
| Cloud-managed | Y |
