| Network |
| Auto-sensing | Y |
| Networking standards | IEEE 802.3af,IEEE 802.3at |
| Flow control support | Y |
| Port mirroring | Y |
| Full duplex | Y |
| Auto MDI (MDI-X) | Y |
| Spanning tree protocol | Y |
| VLAN support | Y |
| 10G support | Y |
| Technical details |
| Vendor | Ubiquiti Networks |
| Ports & interfaces |
| Installed SFP+ modules quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Weight & dimensions |
| Height | 43.7 mm |
| Width | 442.4 mm |
| Depth | 399.6 mm |
| Weight | 6250 g |
| Design |
| LED indicators | Activity, Link, PoE, Speed, System |
| Product colour | Silver |
| Certification | CE, FCC, IC |
| Rack mounting | Y |
| Form factor | 1U |
| Power over Ethernet (PoE) |
| Power over Ethernet plus (PoE+) ports quantity | 40 |
| Total Power over Ethernet (PoE) budget | 600 W |
| Power over Ethernet (PoE) power per port | 64 W |
| Power over Ethernet (PoE) | Y |
| Power |
| Input current | 11.54 A |
| Number of power supply units | 1 |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| DC input voltage | 44 - 57 V |
| Power supply included | Y |
| Operational conditions |
| Operating temperature (T-T) | -5 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Data transmission |
| Throughput | 88000 Mpps |
| Switching capacity | 176 Gbit/s |
| Jumbo frames support | Y |
| Static route | Y |
| Forwarding rate | 130.944 Mpps |
| Security |
| Authentication type | IEEE 802.1x,RADIUS |
| DHCP features | DHCP server |
| Management features |
| Switch layer | L2/L3 |
| Switch type | Managed |
