Design |
| Product colour | Black |
| Wall mountable | Y |
| LED indicators | Y |
| Form factor | 1U |
| Rack mounting | Y |
Power |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power source | AC |
| Power consumption (max) | 166.1 W |
| Power supply included | Y |
Security |
| SSH/SSL support | Y |
| Security algorithms | |
| DHCP features | |
| Loop protection | Y |
| IGMP snooping | Y |
| Password protection | Y |
Operational conditions |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Heat dissipation | 566 BTU/h |
| Operating relative humidity (H-H) | 10 - 95% |
Management features |
| Web-based management | Y |
| Quality of Service (QoS) support | Y |
| Switch layer | L2 |
| Cloud-managed | Y |
| Switch type | Managed |
| MIB support | Y |
Weight & dimensions |
| Depth | 230 mm |
| Weight | 2.48 kg |
| Height | 44 mm |
| Width | 330 mm |
Network |
| Networking standards | |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| 10G support | N |
| Spanning tree protocol | Y |
| Virtual LAN features | Port-based VLAN |
| Flow control support | Y |
| Port mirroring | Y |
| Broadcast storm control | Y |
| VLAN support | Y |
Performance |
| MTBF (PoE) | 768989 h |
| Fanless | Y |
Packaging data |
| Package width | 389 mm |
| Package weight | 3.87 kg |
| Package depth | 337 mm |
| Package height | 79 mm |
Protocols |
| |
| |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
Data transmission |
| Forwarding rate | 35.7 Mpps |
| Jumbo frames | 9000 |
| MAC address table | 8000 entries |
| Switching capacity | 48 Gbit/s |
| Jumbo frames support | Y |
Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget | 130 W |
| Power over Ethernet (PoE) | Y |
| Power over Ethernet (PoE) ports quantity | 12 |
Multicast features |
| |
| |
