Design |
| LED indicators | Y |
| Product colour | Black |
| Electromagnetic compatibility | LVD EN60950-1, BSMI CNS14336-1 |
Power |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| AC input voltage | 200 - 240 V |
| Power consumption (max) | 72 W |
Security |
| MAC address filtering | Y |
| SSH/SSL support | Y |
| IGMP snooping | Y |
Operational conditions |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Operating temperature (T-T) | 0 - 40 °C |
| Heat dissipation | 245.52 BTU/h |
Management features |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| MIB support | RFC 1213 MIB II, RFC 2819, RFC 1215, RFC 1493 |
| Switch layer | L2 |
| Switch type | Managed |
| System event log | Y |
Weight & dimensions |
| Width | 250 mm |
| Depth | 104 mm |
| Weight | 620 g |
| Height | 27 mm |
Network |
| Copper ethernet cabling technology | |
| Networking standards | |
| VLAN support | Y |
| Auto MDI/MDI-X | Y |
| Full duplex | Y |
| 10G support | N |
| Number of VLANs | 8 |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Flow control support | Y |
Performance |
| |
| |
Packaging data |
| User guide | Y |
| Package height | 64 mm |
| Quick start guide | Y |
| Package width | 302 mm |
| Package weight | 1.4 kg |
| Package depth | 227 mm |
| Cables included | AC |
| Manual | Y |
Protocols |
| |
| |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
| Power connector | AC-in jack |
| Gigabit Ethernet (copper) ports quantity | 8 |
Data transmission |
| Switching capacity | 16 Gbit/s |
| Jumbo frames support | Y |
| MAC address table | 8000 entries |
| Packet buffer memory | 525000 MB |
| Jumbo frames | 9000 |
| Forwarding rate | 11.9 Mpps |
Power over Ethernet (PoE) |
| Power over Ethernet (PoE) | Y |
| Total Power over Ethernet (PoE) budget | 60 W |
| Power over Ethernet (PoE) ports quantity | 8 |
Multicast features |
| |
| |
