Design |
| Rack mounting | Y |
| Product colour | Black |
Power |
| Power consumption (max) | 11 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
Security |
| MAC address filtering | Y |
| Security algorithms | |
| DHCP features | |
| IGMP snooping | Y |
| Authentication | Guest VLAN, MAC-based authentication |
| Access Control List (ACL) | Y |
| Authentication type | IEEE 802.1x,RADIUS |
Operational conditions |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Storage relative humidity (H-H) | 10 - 95% |
| Heat dissipation | 37.51 BTU/h |
Management features |
| Web-based management | Y |
| Quality of Service (QoS) support | Y |
| System event log | Y |
| Switch layer | L2 |
| Configuring Location Settings (CLI) | Y |
| Switch type | Managed |
Weight & dimensions |
| Weight | 1.3 kg |
| Width | 267 mm |
| Depth | 162 mm |
| Height | 44 mm |
Network |
| Networking standards | |
| Copper ethernet cabling technology | |
| VLAN support | Y |
| Rate limiting | Y |
| Broadcast storm control | Y |
| Virtual LAN features | |
| Spanning tree protocol | Y |
| 10G support | N |
| Flow control support | Y |
| Link aggregation | Y |
Performance |
| Firmware upgradeable | Y |
| Flash memory | 32 MB |
| Internal memory | 256 MB |
| Fanless | Y |
| Mean time between failures (MTBF) | 1213492 h |
Packaging data |
| Package height | 61 mm |
| Package width | 375 mm |
| Package depth | 235 mm |
| Package weight | 2.21 kg |
| Cables included | AC |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 10 |
Data transmission |
| Packet buffer memory | 1.5 MB |
| MAC address table | 16000 entries |
| Forwarding rate | 15 Mpps |
| Switching capacity | 20 Gbit/s |
Power over Ethernet (PoE) |
| |
| |
Multicast features |
| |
| |
