Design |
| Housing material | Metal |
| LED indicators | |
| Number of fans | 2 fan(s) |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
Power |
| Power consumption (max) | 410 W |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
Security |
| ICMP attack prevention | Yes |
| Security algorithms | |
Operational conditions |
| Storage temperature (T-T) | -20 - 90 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
Management features |
| Switch type | Managed |
| Switch layer | L2+ |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Weight & dimensions |
| Height | 44 mm |
| Width | 440 mm |
| Weight | 2.5 kg |
| Depth | 208 mm |
Network |
| Auto-negotiation | Yes |
| Cable types supported | |
| Virtual LAN features | |
| Auto-sensing | Yes |
| Port mirroring | Yes |
| Flow control support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Broadcast storm control | Yes |
| Link aggregation | Yes |
| Auto MDI/MDI-X | Yes |
| Copper ethernet cabling technology | |
| Full duplex | Yes |
| VLAN support | Yes |
| Networking standards | |
Performance |
| Telnet | Yes |
| Buffer size | 512 KB |
| Noise level | 45 dB |
Packaging data |
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | AC |
Protocols |
| |
| |
Ports & interfaces |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| SFP module slots quantity | 2 |
Logistics data |
| |
| |
Data transmission |
| MAC address table | 8000 entries |
| Forwarding rate | 1.488 Mpps |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Jumbo frames | 9000 |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Store-and-forward | Yes |
| Switching capacity | 36 Gbit/s |
| Jumbo frames support | Yes |
Power over Ethernet (PoE) |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Power over Ethernet (PoE) | Yes |
| Total Power over Ethernet (PoE) budget | 374 W |
| Power over Ethernet (PoE) power per port | 30 W |
