Design |
| LED indicators | Yes |
| Reset button | Yes |
| Rack mounting | Yes |
| Form factor | 1U |
| Product colour | Black |
Power |
| Power supply included | Yes |
| Power consumption (max) | 864.1 W |
| Power source | AC |
| AC input frequency | 50 - 60 Hz |
| AC input voltage | 100 - 240 V |
Security |
| DHCP features | |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Loop protection | Yes |
| SSH/SSL support | Yes |
| MAC address filtering | Yes |
Operational conditions |
| Operating temperature (T-T) | -20 - 50 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Heat dissipation | 864.1 BTU/h |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 70 °C |
Management features |
| MIB support | Y |
| Configuring Location Settings (CLI) | Yes |
| Switch layer | L3 |
| Switch type | Managed |
| Cloud-managed | Yes |
| Quality of Service (QoS) support | Yes |
| Web-based management | Yes |
Weight & dimensions |
| Height | 44 mm |
| Depth | 330 mm |
| Width | 441 mm |
| Weight | 4.85 kg |
Network |
| Policy-based routing | Yes |
| Rate limiting | Yes |
| Broadcast storm control | Yes |
| Spanning tree protocol | Yes |
| VLAN support | Yes |
| Flow control support | Yes |
| 10G support | Yes |
| Number of VLANs | 4000 |
| Networking standards | |
| Ethernet LAN data rates | 10,100,1000,2500,10000 Mbit/s |
Performance |
| |
| |
Packaging data |
| Cables included | AC |
| Rack mount kit | Yes |
Protocols |
| |
| |
Ports & interfaces |
| Installed SFP+ modules quantity | 2 |
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Power connector | AC-in jack |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Fiber optic connector | SFP+ |
| 10G Ethernet (copper) ports quantity | 4 |
Data transmission |
| Static route | Yes |
| Jumbo frames support | Yes |
| MAC address table | 16000 entries |
| Switching capacity | 240 Gbit/s |
| Forwarding rate | 178.5 Mpps |
| Jumbo frames | 12000 |
Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget | 700 W |
| Power over Ethernet (PoE) ports quantity | 28 |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet plus (PoE+) ports quantity | 20 |
Multicast features |
| |
| |
