| Technical details |
| Vendor | Synology |
| Sustainability compliance | Y |
| Sustainability certificates | CE, RoHS |
| Performance |
| Type | NAS |
| Device class | Small & Medium Business |
| Backup function | Y |
| Backup features | Cloud, iSCSI LUN |
| Noise level | 52.3 dB |
| Built-in FTP server | Y |
| System log | Y |
| Snapshot | Y |
| Card reader integrated | N |
| Access Control List (ACL) | Y |
| Security algorithms | AES |
| Management protocols | SNMP |
| Multilingual support | Y |
| Browser supported | Google Chrome Firefox Microsoft Edge Safari |
| Design |
| Chassis type | Rack (2U) |
| LED indicators | Y |
| Product colour | Black, Grey |
| Built-in speaker(s) | N |
| Number of fans | 3 fan(s) |
| Cooling type | Active |
| Fan diameter | 60 mm |
| Built-in display | N |
| Storage |
| Number of storage drives supported | 12 |
| Storage interfaces | Serial ATA |
| Supported storage drive types | HDD, SSD |
| RAID levels | 1 |
| Storage drives installed | N |
| Installed storage drive type | N |
| Hot-swap drive bays | Y |
| Supported file systems | BTRFS, Fat, HFS+, NTFS, exFAT, ext3, ext4 |
| Online RAID migration | Y |
| Online RAID expansion | Y |
| RAID support | Y |
| Storage drive sizes supported | 2.5.3.5 " |
| Memory |
| Internal memory | 8 GB |
| Maximum RAM supported | 32 GB |
| ECC | Y |
| Internal memory type | DDR4 |
| Memory slots | 2 |
| Memory form factor | UDIMM |
| Power |
| Redundant power supply (RPS) support | N |
| Power supply unit (PSU) capacity | 500 W |
| Power consumption (typical) | 119.95 W |
| Number of power supply units | 1 |
| AC input frequency | 50/60 Hz |
| AC input voltage | 100 - 240 V |
| Power supply location | Built-in |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports | 3 |
| PCI Express x8 (Gen 3.x) slots | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB port | Y |
| Software |
| Operating system | DiskStation Manager |
| Operating system version | 7.1.1 |
| Network |
| Ethernet LAN | Y |
| Wake-on-LAN ready | Y |
| Ethernet LAN data rate supported (max) | 10000 Mbit/s |
| Link aggregation | Y |
| Ethernet LAN data rates | 10.100.1000.10000 Mbit/s |
| iSCSI support | Y |
| Copper ethernet cabling technology | 10BASE-T, 10GBASE-T, 100BASE-TX, 1000BASE-T |
| Processor |
| Processor manufacturer | AMD |
| Processor frequency | 3.35 GHz |
| Processor family | AMD Ryzen |
| Processor model | V1780B |
| Processor cores | 4 |
| Number of processors supported | 1 |
| Processor boost frequency | 3.6 GHz |
| Packaging content |
| Rack mount kit | Y |
| Cables included | AC |
| External power adapter | N |
| Power cables quantity | 1 |
| Weight & dimensions |
| Height | 88 mm |
| Width | 482 mm |
| Depth | 562 mm |
| Weight | 11500 g |
| Operational conditions |
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Storage temperature (T-T) | -20 - 60 °C |
| Certificates |
| Certification | FCC BSMI VCCI RCM UKCA EAC CCC KC UL |
